Omcan GR-IT-0373 Instruction Manual page 25

Model GR-IT-1119-M
Model GR-IT-1119-B
Item No. Description
15351 Screw 4x8 (2 pcs.) for FGSM15
15418 Closing Disc ABS 100 mm. for FGSM15
15419 Screw Fixing Roller 10x35 for FGSM15
15420 Washer 10x30x2 for FGSM15
17885 X Flange Standard Roller for FGSM15
17885 X Flange Steel Roller for FGSM15
17823 Grater Punched for FGSM15
17885 X Flange Standard Roller for FGSM15
15423 Screw 5x45 for FGSM15
15424 Pin from 8x57 for FGSM15
15356 Wheat 6x6 (2 pcs.) for FGSM15
15425 Lever Aluminum Grating for FGSM15
71391 Lever Grater with Insert for FGSM15
71392 Micro Switch Cover for FGSM15
15370 Rivets (2 pcs.) for FGSM15
71394 Nottolino for FGSM15
71395 Screw 2.8 x15 (2 pcs.) for FGSM15
71396 Micro Switch Mechanical for FGSM15
11405
39884
Position Item No. Description
1 15430 Mouth Grattugia for FGSM15
2 15410 Screw 8x22 (2 pcs.) for FGSM15
3 15431 Grille for FGSM15
4 15370 Rivets (3 pcs.) for FGSM15
5 17243 Cheese Box for FGSM15
5 15353 Screw 5x30 (4 pcs.) for FGSM15
6 15433 Shell with Hub for FGSM15
7 15434 Bearing 6205 2RS for FGSM15
8 15414 Fixing Ring Fan for FGSM15
9 15415 Fan for FGSM15
Spinetta Stainless Steel 4x10 for
10 17244
FGSM15
11 15437 Gland PG9/11 for FGSM15
11 15436 Crankshaft for FGSM15
12 15446 Rotor for FGSM15
13 78011 6 Pole Stator for FGSM15
14 15417 Long Fan Housing for FGSM15
15 15386 Steel Band Fan for FGSM15
16 15378 Rivets (4 pcs.) for FGSM15
Parts Breakdown
Position Item No.
17 15381
18 15380
19 15353
20 15352
21 15351
22 78025
23 71422
24 78012
25 15439
26 15440
27 19379
28 15411
29 71428
30 44762
31 15412
32 78013
33 15351
34
25
Description Position
Bearing 6203 ZZ for FGSM15 35
Cap Fan for FGSM15 36
Screw 5x30 (4 pcs.) for FGSM15 37
Disc Locking Abs DA 80 mm. for
38
FGSM15
Screw 4x8 (2 pcs.) for FGSM15 39
Gasket Base for FGSM15 40
Keyboard 24V for FGSM15 41
Rubber Feet (4 pcs.) for FGSM15 42
Base for FGSM15 43
Screw 8x25 (2 pcs.) for FGSM15 44
Condenser 25 uF for FGSM15 45
ABS Seat for FGSM15 46
Feet Adhesive Sheet (4 pcs.) for
47
FGSM15
Sheet Low Voltage 24V for FGSM15 48
Screw 4.8 x12 (4 pcs.) for FGSM15 49
Cable with Plug Mod.Schuko for
50
FGSM15
Screw 4x8 for FGSM15 51
