Omcan GR-IT-0373 Instruction Manual page 23

Model GR-IT-0746
Item No. Description
15351 Screw 4x8 (2 pcs.) for FGS-101
15418 Closing Disc ABS 100 mm. for FGS-101
15419 Screw Fixing Roller 10x35 for FGS-101
15420 Washer 10x30x2 for FGS-101
17885 X Flange Standard Roller for FGS-101
17823 Grater Punched for FGS-101
17885 X Flange Standard Roller for FGS-101
15430 Mouth Grattugia for FGS-101
15423 Screw 5x45 for FGS-101
15424 Pin from 8x57 for FGS-101
15356 Wheat 6x6 for FGS-101
15425 Lever Aluminum Grating for FGS-101
15425 Grattugia Lever with Insert for FGS-101
15410 Screw 8x22 (2 pcs.) for FGS-101
17243 Cheese Box for FGS-101
Model GR-IT-1119
Item No. Description
15351 Screw 4x8 (2 pcs.) for FGS-121
15418 Closing Disc ABS 100 mm. for FGS-121
15419 Screw Fixing Roller 10x35 for FGS-121
15420 Washer 10x30x2 for FGS-121
17885 X Flange Standard Roller for FGS-121
17823 Grater Punched for FGS-121
17885 X Flange Standard Roller for FGS-121
15423 Screw 5x45 for FGS-121
15424 Pin from 8x57 for FGS-121
15356 Wheat 6x6 for FGS-121
15425 Grattugia Lever with Insert for FGS-121
15410 Screw 8x22 (2 pcs.) for FGS-121
15430 Mouth Grattugia for FGS-121
17243 Cheese Box for FGS-121
15353 Screw 5x30 (4 pcs.) for FGS-121
11402
Position Item No. Description
1 15353 Screw 5x30 (4 pcs.) for FGS-101
2 15433 Shell with Hub for FGS-101
3 15434 Bearing 6205 2RS for FGS-101
Spinetta Stainless Steel 4x10 for
4 17244
FGS-101
5 15436 Crankshaft for FGS-101
6 15383 Rotor for FGS-101
7 78008 Stator 4 Poles for FGS-101
8 15438 Motor Housing Open for FGS-101
9 15385 Steel Band Short for FGS-101
10 15370 Rivets (4 pcs.) for FGS-101
11 15415 Fan for FGS-101
12 15414 Fixing Ring Fan for FGS-101
12 15381 Bearing 6203 ZZ for FGS-101
13 15380 Cap Fan for FGS-101
14 15353 Screw 5x30 (4 pcs.) for FGS-101
11403
Position Item No. Description
1 15433 Shell with Hub for FGS-121
2 15434 Bearing 6205 2RS for FGS-121
3 15414 Fixing Ring Fan for FGS-121
4 15415 Fan for FGS-121
Spinetta Stainless Steel 4x10 for
5 17244
FGS-121
6 15437 Gland PG9/11 for FGS-121
7 15436 Crankshaft for FGS-121
8 15446 Rotor for FGS-121
9 78011 6 Pole Stator for FGS-121
10 15417 Long Fan Housing for FGS-121
11 15386 Steel Band Fan for FGS-121
12 15370 Rivets (4 pcs.) for FGS-121
13 15381 Bearing 6203 ZZ for FGS-121
14 15380 Cap Fan for FGS-121
15 15353 Screw 5x30 (4 pcs.) for FGS-121
Parts Breakdown
Position Item No.
15 15351
16 15352
17 78009
18 15351
19 15437
20 17701
21 17701
22 15413
23 15412
24 15411
25 15440
26 78024
27 15439
28 78010
29
Position Item No.
16 15352
17 15351
18 78025
19 15463
20 15463
21 78012
22 15439
23 15440
24 19379
25 15411
26 15412
27 15351
28 78013
29
30
23
Description Position
Screw 4x8 (2 pcs.) for FGS-101 30
Disc Locking ABS DA 80 mm. for
31
FGS-101
Cable with Plug Mod.Schuko for
32
FGS-101
Screw 4x8 for FGS-101 33
Gland PG9/11 for FGS-101 34
Bipolar Switch for FGS-101 35
Switch Pole for FGS-101 35
Condenser 16 uF for FGS-101 36
Screw 4.8 x12 (4 pcs.) for FGS-101 37
ABS Seat for FGS-101 38
Screw 8x25 (2 pcs.) for FGS-101 39
Rubber Feet (4 pcs.) for FGS-101 40
Base for FGS-101 41
Gasket Base for FGS-101 42
Description Position
Disc Locking ABS DA 80 mm. for
31
FGS-121
Screw 4x8 (2 pcs.) for FGS-121 32
Gasket Base for FGS-121 33
Bipolar Switch for FGS-121 34
Switch Pole for FGS-121 34
Rubber Feet (4 pcs.) for FGS-121 35
Base for FGS-121 36
Screw 8x25 (2 pcs.) for FGS-121 37
Condenser 25 uF for FGS-121 38
ABS Seat for FGS-121 39
Screw 4.8 x12 (4 pcs.) for FGS-121 40
Screw 4x8 for FGS-121 41
Cable with Plug Mod.Schuko for
42
FGS-121
