- Page 1 Bowl Cutters Models FP-IT-0004-VT, 0006-VT, 0009-VT Items 47261, 47269, 47083 Instruction Manual Revised - 12/08/2021 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model FP-IT-0004-VT / Model FP-IT-0006-VT / Model FP-IT-0009-VT Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 7 Operation --------------------------------------------------------------------------------------------- 8 Maintenance ------------------------------------------------------------------------------------- 8 - 9... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 6: Technical Specifications
Safety and Warranty Please see https://omcan.com/disclaimer for complete info. WARNING: The packaging components are classified as normal solid urban waste and can therefore be disposed of without difficulty. In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. -
Page 7: Installation
Installation CHECKS ON DELIVERY When you receive the package containing the machine, carefully check the packaging for signs of damage during shipping. If the packaging shows signs of mishandling, impacts or dropping, report the damage to the shipping agent within three days of the date of delivery indicated on the documents and draw up a detailed report on any damage to the product. -
Page 8: Operation
Operation CONTROLS The commands are placed on the body of the cutter. These include the ON button, the OFF button, the PULSE button and the SPEED knob to regulate the speed. Use the ON button to switch the machine on, and OFF to switch the machine off, rotate the speed knob clockwise to increase the revolutions and anti-clockwise to reduce them. -
Page 9: Maintenance
Maintenance electroshock risks. • After cleaning, carefully dry all parts part of the cutter and put them back together again. CLEANING THE LID, BLADE HOLDER AND TANK Rotate the closing arm to remove the lid. You can now easily remove the blade holder and tank by pulling them upwards. -
Page 10: Parts Breakdown
Parts Breakdown Model FP-IT-0004-VT 47261 Model FP-IT-0006-VT 47269... - Page 11 Parts Breakdown Model FP-IT-0004-VT 47261 Item No. Description Position Item No. Description Position Item No. Description Position AH741 Scraper Spatula 4 for 47261 AH755 Control Unit NC 11 01 for 47261 AH769 Rubber Grommet 9 for 47261 Switching Power Supply 24VDC 12W AH742 Base 6 Bril.
- Page 12 Parts Breakdown Model FP-IT-0006-VT 47269 Item No. Description Position Item No. Description Position Item No. Description Position AH784 Scraper Spatula 6 for 47269 AH755 Control Unit NC 11 01 for 47269 AH769 Rubber Grommet 9 for 47269 Switching Power Supply 24VDC 12W AH742 Base 6 Bril.
- Page 13 Parts Breakdown Model FP-IT-0009-VT 47083...
- Page 14 Parts Breakdown Model FP-IT-0009-VT 47083 Item No. Description Position Item No. Description Position Item No. Description Position AH792 Scraper 9 for 47083 AH798 Cover Compl. + Guarn. 9 for 47083 AH807 Long Foot Plate 9 for 47083 AH793 Base 9 Bril. for 47083 AH758 Cover Cap 9 for 47083 AH808...
-
Page 15: Electrical Schematics
Electrical Schematics Model FP-IT-0004-VT 47261 Model FP-IT-0006-VT 47269 Model FP-IT-0009-VT 47083... -
Page 16: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 17 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 18 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 19: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 20 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
