Novus ND0115 User Manual

15 channel distribution amplifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
15 Channel Distribution Amplifier
All information provided herein is the property of Novus Power Products LLC. The
information included may be reproduced without the permission of Novus Power
Products LLC for the purpose of operating the equipment.
Page #:
1 of 48
USERS MANUAL
REVISION NO.
DATE
ND0115
www.novuspower.com
ND0115
H
6/01/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ND0115 and is the answer not in the manual?

Questions and answers

Related Manuals for Novus ND0115

Summary of Contents for Novus ND0115

  • Page 1 DATE ND0115 15 Channel Distribution Amplifier All information provided herein is the property of Novus Power Products LLC. The information included may be reproduced without the permission of Novus Power Products LLC for the purpose of operating the equipment. Page #: 1 of 48 www.novuspower.com...

  • Page 2: Table Of Contents

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Contents 1.0 Summary ......................3 2.0 Controls and Indicators – Front Panel ............. 5 2.1 Channel Status .................... 6 2.2 Status LEDs ....................7 2.3 Input Status ....................7 2.4 Power Supply Status ................... 8 2.5 Attenuation ....................

  • Page 3: Summary

    6/01/17 DATE 1.0 Summary The ND0115 is a 15/16 channel wide bandwidth distribution amplifier. While primarily used for 10 MHz reference distribution, it has a functional bandwidth from DC to 12 MHz, but is filtered for the lowest phase noise 10MHz signal.
  • Page 4 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE The amplifier can also be optionally redundant. The redundancy feature adds a second power supply and a second 15/16 channel amplifier PCB assembly. The dual input design monitors the input signals and selects the active signal or the prioritized signal.

  • Page 5: Controls And Indicators - Front Panel

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 2.0 Controls and Indicators – Front Panel This section describes the functionality of the front panel controls and indicators. Two buttons above the status LEDs provide navigation through the menus. In general, the NEXT button advances through the menus to the next screen, while the SELECT button chooses between the available values on a menu.

  • Page 6: Channel Status

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 2.1 Channel Status The Channel Status can be determined by reading the actual RMS value on the output of each stage. This is compared to a threshold limit that is set by the user as a percentage variation from a saved value.

  • Page 7: Status Leds

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE The current threshold limits are displayed in addition to the actual measured value. These values reflect the percentage threshold defined in the Alert Threshold settings. If the output value is too low to give a valid reading - the display will read “LOW.”...

  • Page 8: Power Supply Status

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE If no input is present, or the input selection priority does not have an input value which is above the input threshold, the ALERT LED flashes red, and the screen indicates “Connect Source.” The error is also noted in the fifth field of the $GPNVS...
  • Page 9 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE The values of both DC supplies are measured internally to validate connections. The measured values of the AC/DC converter and the DC input are reported in the third and fourth fields of the second $GPNVS status string.

  • Page 10: Attenuation

    If a communications failure is reported, the backup system will automatically switch to the redundant system. 2.5 Attenuation The ND0115 is equipped with an internal 6-bit programmable attenuator for each input channel. This feature can be used to better match input signals if cabling differences exist. The attenuation value is RS232 programmable with values 0x01 to 0x3F (1 –...

  • Page 11: Alert Threshold

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Note: The 0dB point is approximately set to 45 or 0x2D on the 6-bit attenuator. This is equivalent to the 0% value on the Attenuation menu. To fine-tune the attenuation for each channel, program the attenuation between 1 and 63 (0x01 to 0x3F) via the front or rear panel RS232 port.
  • Page 12 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE channel, any subsequent deviation on that channel which exceeds the Alert Threshold percentage will trigger an alert. Steps to ensure correct Alert configuration: 1. Connect source input(s) to channel A and/or B. 2. Connect distribution cabling to channels 1 through 16.
  • Page 13 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE The Alert Threshold can be optimized so that a channel short or an impedance change will cause an Alert. Page #: 13 of 48 www.novuspower.com...
  • Page 14 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Example: The output of channel 1 is connected to a high impedance input and reports 1.25Vrms at the output. The output of channel 2 is connected to a 50Ohm terminated input, and reports 0.90Vrms at the output.

  • Page 15: Input Threshold

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 2.7 Input Threshold The Input Threshold Screen allows the user to monitor and set the threshold at which the input is regarded as invalid or faulted. The Input Threshold value is the absolute voltage (user programmable between 0.1Vrms and 1Vrms) below which the...

  • Page 16: Input Select

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 2.8 Input Select The Input Select screen allows the user to monitor and select the Input Priority for inputs A and B. Pressing the SELECT button will advance through the following settings: - Input A select...

  • Page 17: Latch Channel Values

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 2.9 Latch Channel Values The Latch Channel Values Screen allows the user to save the current channel output values for use as the Reference Value for Alert settings. A channel Alert is triggered when a channel output voltage exceeds or falls below a percentage of the Reference Value.

  • Page 18: Fault Status

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE To save the current settings, press the SELECT button twice. The Save Configuration action is equivalent to the $SAVEFL command on the serial port. 2.10 Fault Status The Fault Status screen allows a quick overview of any channel faults from the front panel.

  • Page 19: Power Switch

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE The System Fault Screen indicates any failures in the primary system or the redundant backup system. All internal power supplies are monitored (24V, +8V, -8V, 5V) on both the primary and backup systems. A failure on one of these supplies will be indicated with a “PS FAIL”...

  • Page 20: Rs232 Db9 Port

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 2.12 RS232 DB9 Port The front panel RS232 port allows convenient setup of the unit in addition to the rear panel RS232 which may be connected to a more permanent instrumentation setup. The front panel RS232 port will respond to the same commands as the rear panel and any changes made will be reported on both serial ports.

  • Page 21: Rear Panel

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 3.0 Rear Panel 3.1 Channel Ouputs - BNC There are 15 outputs across the left-hand side of the rear panel. They are labeled 1 through 15. These can be sine or square wave depending upon the factory configuration.

  • Page 22: Signal Input A/B

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 3.3 Signal Input A/B Signal input. Standard impedance is 50 Ohms. Maximum signal input is 1.5 Vrms. By default, Auto(A) priority is selected, meaning Signal A is considered primary, and B is used if A is detected as being out-of-tolerance.

  • Page 23: Rs232 Db9

    An RS232 port is provided for local setup and status monitoring. The embedded processor provides status strings as well as command responses. Configuration and status commands are detailed in the ND0115 Programmer’s Manual Section 5.0. RS232 Serial Port: Rear Panel Pin Connections...

  • Page 24: Optical Port

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 3.7 Optical Port Optional optical connector provides connection to optical transmitter and pass through for daisy chained configurations. The panel mount optical coupler is Broadcom P/N HFBR- 4505Z. 4.0 Functional Description Page #: 24 of 48 www.novuspower.com...

  • Page 25: Bandwidth

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Each redundant amplifier PCB section is relayed to the output source and outputs are monitored consistently. In the event of amplifier failure, the redundant assembly can be relayed in and the affected assembly is relayed out. See Amplifier Test in the programming Section.
  • Page 26 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Page #: 26 of 48 www.novuspower.com...

  • Page 27: Outputs

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 4.3 Outputs Each output is fault and electrostatic discharge protected. Each output is independent and any output can be faulted for an indefinite period of time with no permanent damage. Each output is connected to a monitor circuit that detects a local fault on the output.
  • Page 28 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Optional CMOS or TTL level buffer with 20mA drive, fault protected and relayed. Optional low impedance source output up to 100mA drive capability. Page #: 28 of 48 www.novuspower.com...

  • Page 29: Built In Test

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE The nominal application is for a 10MHz sine wave output in the range of 1 Vrms. The unit also be ordered with a square option. Any number of channels may be ordered to provide a 5Vdc 50% duty cycle square wave output.

  • Page 30: Amplifier Test

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE There is an EMI filter between the internal power supply and the available power being used. This filter minimizes the electrical noise from entering the circuitry and negatively impacting noise performance. Also, in most applications, the...
  • Page 31 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE If a fault occurs while the AMP test is enabled, the unit will disengage the relay to the active amplifier assembly, and engage the relay to the ancillary amplifier assembly. Next, with the amplifier to the affected channel unloaded, the affected...

  • Page 32: Programming Guide (Rs232 Port: Front And Rear)

    5.0 Programming Guide (RS232 Port: Front and Rear) The ND0115 can accept user commands which will provide specific fault detection performance which may be customized by the user. The settings can be saved in non-volatile flash memory.
  • Page 33 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Table 1 shows a complete list of input commands and descriptions. In general, a command may be input without “=” or an additional value, and the unit will respond with the current setting’s value. If the input is not understood, the microcontroller will return the value “$?*3F<CR><LF>...

  • Page 34: Rs232 Commands

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 5.1 RS232 Commands Command Setting Response Description Query attenuation setting of 6-bit potentiometer on $ATT active input (A or B). Returns two digit decimal formatted number (00-63) INPUT Set Attenuation on currently active Input channel. If $ATT=<current Attenuation setting>...
  • Page 35 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Page #: 35 of 48 www.novuspower.com...
  • Page 36 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Setting Command Response Description $SET<nn>=n.nn Set or query the Reference Voltage for a perticular channel with respect to the active input. Use in combination with the Channel Fault Threshold Factor to define Alert on an individual Channel.
  • Page 37 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Command Response Description $CAL<n>=nn.nn Query or set Cal Factors for specific ADC conversions. See list of Cal Factors numbered for CAL FACTORS $CAL<n>=nn.nn appropriate measurement parameters. These $CAL1=11.10 settings should only be changed by an authorized technician.
  • Page 38 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Setting Command Response Description Enables an amplifier gain test when fault is triggered. If AMP=1, when a fault occurs on a $AMP specific channel, the controller will switch to the backup amplifier assembly, and check the open circuit gain of the affected board.

  • Page 39: Status String ($Gpnvs,1) Channel Measurements

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 5.2 Status String ($GPNVS,1) Channel Measurements $GPNVS 1 n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn n.nn * # Description Range 1. Identifier $GPNVS 2. String ID 0.00 –...

  • Page 40: Status String ($Gpnvs,2) Power Supply Measurements

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 5.3 Status String ($GPNVS,2) Power Supply Measurements $GPNVS 2 n.nn n.nn n.nn n.nn n.nn n.nn n.nn ±nnC # Description Range 1. Identifier $GPNVS 2. String ID 3. 24V AC/DC Internal 0.00 to 36.0 [V] 4.

  • Page 41: Status String ($Gpnvs,3) Status Bytes

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 5.4 Status String ($GPNVS,3) Status Bytes $GPNVS 3 0 A 0 0x0000 0x00 0x00 0x00 0x0000 0x0000 0x0000 2 3 4 # Description Range 1. Identifier $GPNVS 2. String ID 3. Active PCB Assembly 0 or 1 4.

  • Page 42: Status Byte Key

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 5.5 Status Byte Key Hex Value (OR'd) Channel ID Channel Status Word 0x1<<0 Channel 1 Fault 0x1<<1 Channel 2 Fault 0x1<<2 Channel 3 Fault 0x1<<3 Channel 4 Fault 0x1<<4 Channel 5 Fault 0x1<<5 Channel 6 Fault 0x1<<6...
  • Page 43 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Hex Value (OR'd) Channel ID Primary PCB Amp Status 0x1<<0 Channel 1 Fault 0x1<<1 Channel 2 Fault 0x1<<2 Channel 3 Fault Internal Fault Primary 0x1<<3 Channel 4 Fault Assembly: The channel 0x1<<4 Channel 5 Fault has failed an internal 0x1<<5...
  • Page 44 ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE Hex Value (OR'd) Status Message 0x1<<0 8V(-) PS out of range 0x1<<1 Reserved Primary and 0x1<<2 Reserved Secondary 0x1<<3 8V(+) PS out of range Power Supply 0x1<<4 5V PS out of range Status 0x1<<5...

  • Page 45: Calibration Factors

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 5.6 Calibration Factors Calibration Default Description Value CAL00 24Vdc Input Adjust 11.30 CAL01 AC/DC 24V Adjust 11.10 CAL02 Input A Vrms Adjust 2.85 CAL03 Input B Vrms Adjust 2.72 CAL04 Reserved 0.00 CAL05 Reserved 0.00...

  • Page 46: Specifications

    ND0115 USERS MANUAL REVISION NO. 6/01/17 DATE 6.0 Specifications 6.1 Technical Specifications Linear Amplifier 20KHz to 15MHz ±2db, 1.5 Vrms Max(Option to DC available) Bandwidth Impedance 50 Ohm Optional Square Wave Any channel can be configured to have a square wave output.

  • Page 47: Limited Hardware Warranty

    1 (one) year to be free from defects caused by faulty materials or poor workmanship, provided: (a) NOVUS is notified in writing by Buyer of such defect prior to the expiration of the warranty period, and (b) after receiving return authorization –RMA- from NOVUS, the defective item is returned with transportation prepaid to NOVUS, Independence, Missouri, with transportation charges prepaid by Buyer …see RMA policy in Terms and conditions, and...
  • Page 48 (ninety) days. PRODUCT SPECIFICATIONS: Published specifications whether contained herein or in any other materials or documents distributed to Buyer by Novus do not become final or binding on NOVUS until approved by NOVUS. NOVUS expressly reserves the right to change or modify specifications at any time without prior notice.
