Prius '04-'09
The Proximity / Remote Fob
"Learning Slot" is located on the
right side of the driver's dash.
On models without the "Smart
Access" feature installed the Prox
must be inserted into the slot for
the vehicle to be driven.
Dealer Part# 89070-47180
Black logo on back is for basic Prius
models and do not
have Smart Access Proximity.
Smart Access Proximity Prius models have a Rubber Push
Button on the front door handles.
This makes it easy to tell by just looking at the car which FOB
The different Fobs shown above are NOT interchangeable.
576
TOYOTA
Sp e ci a l I n s t ru c t io n s

Security Components

All Prius 2004-2009 models have a
Push Start Button on the dash.
to use.
Models with the Smart Access Proximity system have a
"Lock-Out" button on the bottom of the dash, below the steering
column.
Make sure the button is in the "Out" position (not depressed).
Advanced Diagnostics USA Manual for MVP & TCODE PRO – Copyright 2014 Advanced Diagnostics USA INC.
PRIUS '04-'09
ADVANCED DIAGNOSTICS USA
Dealer Part# 89994-47061
Chrome logo on back is for
Smart Access
Proximity Prius models.
