Panel views
OAP Smart MIM Module
Figure 1 Front panel
(1) USB port
(3) LINK LED for the GigabitEthernet management port
(4) Stand By button
(6) Disk LED (DISK)
OAP MIM Module
Figure 2 Front panel
(1) USB port
(3) LINK LED for the GigabitEthernet management port
(4) Stand By button
(6) Disk LED (DISK)
(2) 100/1000Base-T Ethernet port LED
(5) System status LED (SYS)
(7) GigabitEthernet management port
(2) 100/1000Base-T Ethernet port LED
(5) System status LED (SYS)
(7) GigabitEthernet management port
2
