Stand By Button - H3C MSR Series User Manual

LED mark
DISK
LINK/ACT
100/1000M

Stand By button

Table 3 Stand By button operation description
System status
The OAP module is
power off.
The OAP module is
powered on.
Status
Steady green
Flashing green
Steady yellow
Off
Steady yellow
Flashing yellow
Off
(Suppose the LINK/ACT
LED is yellow)
Steady orange
(Suppose the LINK/ACT
LED is yellow)
Steady green
(Suppose the LINK/ACT
LED is yellow)
Operation
Press the Stand By button.
Press and hold the Stand By
button for less than four
seconds.
Press and hold the Stand By
button for more than four
seconds.
Description
The disk is in position.
The disk is performing a read/write
operation.
A problem has occurred to the disk.
The disk is not in position.
A link is present on the port.
Data is being transmitted or received
over the link.
A 10 Mbps link is present.
A 100 Mbps link is present.
A 1000 Mbps link is present.
Description
The module is turned on
and the system starts up.
Soft off (the system is shut
down first and then the
module is powered off.)
Force a shutdown.
4
