U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY
NOTE : This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet of a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for assistance.
PRESTIGIO P170T / P190T
Prestigio P170T / P190T
User's Manual
INTERFERENCE STATEMENT
INFORMATION TO THE USER
1
Advertisement
Table of Contents
Related Manuals for Prestigio P170T
Summary of Contents for Prestigio P170T
- Page 1 Prestigio P170T / P190T User’s Manual U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 2: Safety Information
1. Introduction This manual contains instructions for installing and operating Prestigio P170T / P190T. Prestigio P170T / P190T is a highly ergonomic color display unit. • 17"/19” viewable SXGA LCD • High quality screen re-scaling capability • 100-240V AC input voltage, DC 12V 3.5A Adapter •... -
Page 3: Installing The Monitor
Note: The power cord above can be changed upon different voltage areas. Please contact your dealer if anything is missing or damaged. Other power cord’s except the original packed in the product especially cards longer than 3m may affect EMC of the product in operating condition. PRESTIGIO P170T / P190T... -
Page 4: Selecting A Suitable Location
Troubleshooting section of this guide. 5. Turn on the power of the computer. The picture will appear within about 10 seconds. Adjust the picture to obtain optimum picture quality. See section Adjusting the picture in this guide for more information. PRESTIGIO P170T / P190T... -
Page 5: Connecting The Tv
When the monitor is turned on, audio is always set up as off mode. Please use AUDIO direct access button on the front cover or On Screen Display to put audio on. PRESTIGIO P170T / P190T... -
Page 6: Setting The Refresh Rate
60 Hz 1024 x 768 56.5 KHz 70 Hz 1024 x 768 60.0 KHz 75 Hz 1152 x 864 67.5 KHz 75 Hz 1280 x 1024 63.9 KHz 60 Hz 1280 x 1024 80.0 KHz 75 Hz PRESTIGIO P170T / P190T... -
Page 7: User's Environment
* Ergotron, Inc. • Address : Ergotron Europe Kuiperbergweg 50 1101 AG Amsterdam The Netherlands • Tel : +3 1 20 696 60 65 • Fax : +3 1 20 609 04 59 • E-mail : info.eu@ergotron.com PRESTIGIO P170T / P190T... -
Page 8: Adjusting The Picture
At first, a full screen such as Window’s back ground will be displayed. Push the SELECT(AUTO) button to adjust the shape of the screen automatically. VOLUME Use the VOLUME button to select the volume adjustment. Adjust with \/ or /\ button. PRESTIGIO P170T / P190T... -
Page 9: Auto Adjust
Optimum color setting is auto programmed for user’s SOURCE convenience. No function. (Only supportable by the optional appliance.) AUDIO VOLUME Adjust the audio volume level. SOUND OFF This menu is used to choose audio on / off. PRESTIGIO P170T / P190T... - Page 10 Open the On-Screen-Display and select the highlighted function. SELECT Select a function on the OSD. \/ /\ Moves the selector right or left on the OSD. Increases or decreases the values of the selected function. Increases or decreases the channel number. PRESTIGIO P170T / P190T...
- Page 11 Adjusts the OSD menu’s horizontal or vertical position on the screen. TV INPUT Select a channel system : Air or Cable. P190T ONLY TELETEXT(OPTION) AUDIO VOLUME Adjusts the audio volume level. SOUND OFF This menu is used to turn the choose audio on /off. PRESTIGIO P170T / P190T...
-
Page 12: Channel Search
In order to watch TV, Multimedia Kit shall be installed to your monitor. Following instructions are based on using remote controller, and MENU button in remote controller is compatible with SELECT button of the monitor. You can scan for the frequency ranges available in your country. PRESTIGIO P170T / P190T... - Page 13 - buttons. Then press EXIT. g. You can save or delete above changes by selecting STORAGE or DEL button by pressing MENU button. When storage or delete is finished, you can see YES in the menu, then press EXIT. PRESTIGIO P170T / P190T...
- Page 14 2. To see the actual broadcast simultaneously with the teletext page, press TTX/MIX button again. 3. Press TTX/MIX button again to exit from the teletext mode. Note: If you press MENU when you watch teletext information, you can go back to the top page. PRESTIGIO P170T / P190T...
-
Page 15: Other Functions
TV INPUT First of all, you can select the Air or Cable before setup the Channel Searching. 1. Press the MENU button and select TV icon. 2. Move cursor to TV INPUT using the +/- buttons. PRESTIGIO P170T / P190T... -
Page 16: Channel Edit
• Channel Fine Tune 1. Select CH FINE TUNE by +/- buttons, then press MENU button. You can adjust CH FINE TUNE value by +/- buttons. 2. Press the EXIT button to go back to the previous menu. PRESTIGIO P170T / P190T... -
Page 17: Display Power Management
Power consumption Normal Green 40 W Orange P170T < 3.5 W / P190T < 5 W Unplugged Not illuminated Note: The power button does not disconnect the monitor from the mains. The only way to isolate the monitor completely from the mains supply is to unplug the mains cable. -
Page 18: Contacting Service
If the monitor is sent for service, use the original package if possible. Unplug the unit from the power outlet and contact a service agent when: • The monitor does not operate normally according to the operating instructions. PRESTIGIO P170T / P190T... -
Page 19: Maximum Bandwidth
Input voltage Weight DC 12V 3.5A 4.5Kg unpacked, 6.0Kg packed Power consumption Dimensions (W X H X D mm) 372 X 395 X 185 mm • Specification is subject to change without notice for performance improvement. PRESTIGIO P170T / P190T... - Page 20 Input voltage Weight DC 12V 3.5A 4.9Kg unpacked, 6.8Kg packed Power consumption Dimensions (W X H X D mm) 420 X 441 X 185 mm • Specification is subject to change without notice for performance improvement. PRESTIGIO P170T / P190T...
