Summary of Contents for Prestigio P323MW
- Page 1 Prestigio P323MW / P373MW User’s Manual Trademarks All brand and product names are trademarks or registered trademarks of their respective companies. Note The information in this manual is subject to change without notice. PRESTIGIO P323MW / P373MW...
-
Page 2: Important Safety Information
7. During the LCD panel lifespan it is normal for a few pixels to become defective. Non-active pixels may appear on the screen as fixed points of red, blue or green. Refer pixel policy questions to your dealer for further clarification on acceptable loss. PRESTIGIO P323MW / P373MW... -
Page 3: Table Of Contents
Using the SCART Connection ............................... 23 4.4 Connecting to Another Device’s Video/Audio Input Connector ................24 CHAPTER 5 More Features ............................25 5.1 Changing the Aspect Ratio ..........................25 Using the Remote Control ..............................25 Using the OSD ..................................25 PRESTIGIO P323MW / P373MW... -
Page 4: Preface
* Chapter 6, Adjusting LCD TV Settings, describes how to adjust the settings using the On Screen Display (OSD). * Chapter 7, Troubleshooting, gives solutions to common problems. * Appendix A, Specifications, provides brief specifications and regulatory information for the LCD TV. PRESTIGIO P323MW / P373MW... -
Page 5: Chapter 1 Quick Setup
1. Prepare two AAA batteries. It is recommended that the batteries are of the same type and manufacturer. (Two batteries are supplied with your LCD TV.) 2. Remove the battery door by pressing inwards on the battery latch and lifting it up and away from the remote control. PRESTIGIO P323MW / P373MW... -
Page 6: Mounting The Lcd Tv On The Wall (Optional)
2. Remove the screws connecting the stand to the LCD TV. NOTE: The speaker does not have to be removed to remove the stand. 3. Pull outwards on the base to detach the stand from the LCD TV frame. PRESTIGIO P323MW / P373MW... -
Page 7: Basic Connections
1. Prepare an F-type coaxial cable. 2. Connect one end of the corresponding coaxial cable to the TV1 input connector. Connect the other end to an antenna or cable TV connector on the wall. PRESTIGIO P323MW / P373MW... -
Page 8: Connecting Power
When using the LCD TV for the first time, make sure that the main power switch located on the rear of the LCD TV is set to the on ( I ) position. The power indicator on front of the LCD TV will illuminate orange, indicating that the TV has power and is currently in standby mode. PRESTIGIO P323MW / P373MW... -
Page 9: Power Button
To turn the TV off, press the POWER button located on the right side panel of the TV or the power button on the remote control. The power indicator on front of the LCD TV lights orange to indicate that the TV is in off (standby) mode. PRESTIGIO P323MW / P373MW... -
Page 10: Chapter 2 Introducing Your Lcd Tv
* AV output support 2.2 Front Panel Indicators Ref. Component Description See Also Remote Sensor Receives signal input from the remote control. Power Indicator Green: On Section 1.4 Orange: Standby Off: Main power off (see Rear Panel Inputs/Outputs) PRESTIGIO P323MW / P373MW... -
Page 11: Rear Panel Inputs/Outputs
TV In Connector Connects to a UHF antenna or cable TV. Chapter 1 Power Connector Connects to an A/C outlet for powering the display. Section 1.3 Main Power Switch Turns the main power on and off. Section 1.4 PRESTIGIO P323MW / P373MW... -
Page 12: Rear Right-Side Inputs/Outputs
(Audio L/R, CVBS in/out, S-video in) Chapter 4 SCART 2 (Audio L/R, CVBS in/out, RGB) Connectors Connects to video and audio equipment such as VCRs, DVD players, digital set top boxes, and gaming systems that utilize SCART video. PRESTIGIO P323MW / P373MW... -
Page 13: Right-Side Panel Inputs/Outputs
Opens or closes the OSD menu. Chapter 6 SOURCE Button Switches to another input source (TV, AV1, AV2, AV3, SV1, SV2, SCART2 RGB, VGA, and YPbPr). Power Button Turns the TV ON and OFF (standby). Section 1.4 PRESTIGIO P323MW / P373MW... -
Page 14: Remote Control
See Also Number Enter a TV channel number or Section 5.4 (0, 1 to 9) specify the page number in teletext. Enters a password when parental control are in use. P>P Returns to the previously viewed channel. PRESTIGIO P323MW / P373MW... - Page 15 Green Executes the green function in Section 5.6 button the teletext window. Yellow Executes the yellow function in Section 5.6 button the teletext window. Blue Executes the blue function in Section 5.6 button the teletext window. PRESTIGIO P323MW / P373MW...
-
Page 16: Chapter 3 Watching Tv
1. Press the MENU button to open the OSD main menu. 2. Press the P- button three times and press OK to open the System menu. 3. Press the P- button to select Country and press V- or V+ to select your country. PRESTIGIO P323MW / P373MW... -
Page 17: Scanning Tv Channels (Uhf Antenna Only)
* Pressing or on the remote control * Pressing VOL /\ or VOL \/ on the right panel of the TV To mute the sound, press the mute button on the remote control. To end the mute, press the same button again. PRESTIGIO P323MW / P373MW... -
Page 18: Selecting Mono/Stereo Mode
2. Press the P- or P+ button to highlight one program to be moved. Then press V+ button. 3. Press the P- or P+ button to highlight the second program to be interchanged with. Then press the V- button. The two-program sequence has been rearranged. PRESTIGIO P323MW / P373MW... -
Page 19: Chapter 4 Connecting External Devices
SCART is used for combined audio (usually in stereo) and video (VHS, S-VHS, and RGB signals), making connections much simpler, by providing one plug that contains all the necessary signals, and is standard across different manufacturers. PRESTIGIO P323MW / P373MW... -
Page 20: Connecting A Dvd Player
3. Connect the R (red) and L (white) audio cable ends to the R-Audio-L connectors at the AV3 location on the LCD TV. Connect the other ends to the corresponding left and right audio connectors on the DVD player. PRESTIGIO P323MW / P373MW... -
Page 21: Using The Scart Connection
SV1 or SCART2 RGB as the input source. Press ENTER to confirm SV1 or SCART2 RGB as your selection. 4. Turn on the DVD player. NOTE: For more information, see the instructions supplied with your DVD player. PRESTIGIO P323MW / P373MW... -
Page 22: Connecting A Vcr, Camcorder, Or Game Console
P- button to scroll through the source list and select AV3 as the input source. Press OK to confirm AV3 as your selection. 5. Turn on the VCR / camcorder / game console. NOTE: For more information, see the instructions supplied with your VCR, camcorder, or game console. PRESTIGIO P323MW / P373MW... -
Page 23: Using The Scart Connection
SV1 or SCART2 RGB as the input source. Press ENTER to confirm SV1 or SCART2 RGB as your selection. 4. Turn on the VCR / camcorder / game console. NOTE: For more information, see the instructions supplied with your VCR / camcorder / game console. PRESTIGIO P323MW / P373MW... -
Page 24: Connecting To Another Device's Video/Audio Input Connector
3. Connect the R (red) and L (white) audio cables (not supplied): one end to the LCD TV and the other end to the other LCD TV or audio recording device. 4. Turn on the other LCD TV or video/audio recording device. NOTE: For more information, see the instructions supplied with the other LCD TV or video/audio recording device. PRESTIGIO P323MW / P373MW... -
Page 25: Chapter 5 More Features
2. Press OK to open the Picture Menu. 3. Press the P- button to select Form. 4. Press the V+ or V- button to select 4:3 Expanded, 16:9, 4:3, or Panorama. 5. Press OK to activate your selection. PRESTIGIO P323MW / P373MW... -
Page 26: Using Hold
You can use the OSD to activate PIP (small/medium/large window). 1. Press the MENU button to open the OSD main menu. 2. Press the P- button five times to select the last icon and press OK to open the Calibration Menu. PRESTIGIO P323MW / P373MW... -
Page 27: Part 2. Selecting The Input Source
If you select TV as the PIP source, press P+ or P-, or input the channel number to change channels. The following are the allowable PIP sources: TV, AV1, AV2, AV3, SV1, SV2, SCART2 RGB, VGA, YPbPr. PRESTIGIO P323MW / P373MW... -
Page 28: Adjusting Pip Display And Sound Output
7. Under the Lock submenu, press V+ or V- button to select any of the following. * No No parental control is set. * All All type of viewing is set under parental control and you need to input the password to view any program. PRESTIGIO P323MW / P373MW... -
Page 29: Viewing Blocked Program
7. Press the P- button to select Off Timer, then use the V+ or V- button to set the time for your TV to sleep automatically. 8. Press the P- button to select Active, then use the V+ or V- button to activate the sleep timer. PRESTIGIO P323MW / P373MW... -
Page 30: Using Teletext
7. Press SIZE to zoom in to the top part of the page. Press SIZE the second time to zoom in on the bottom part of the page. Pressing SIZE a third time will restore the normal view. PRESTIGIO P323MW / P373MW... -
Page 31: Chapter 6 Adjusting Lcd Tv Settings
You can also use the right side panel buttons for the same purpose. Changing the OSD Language By default, the OSD language is set to English. You can switch the language to French, Spanish, etc. via the System sub- menu. (See Section 6.5 for more information.) PRESTIGIO P323MW / P373MW... -
Page 32: Picture Menu
Standard, or Cold. activate your selection. Form Set the aspect ratio to Extended 16:9 (full screen), V+ to select Normal. Extended 4:3, 4:3 (traditional TV screen), or non-linear. V- to select Wide. OK to activate your selection. PRESTIGIO P323MW / P373MW... -
Page 33: Sound Menu
OK to activate the function. A check mark indicates enabled. Enable the aptitude volume. OK to activate the function. A check mark indicates enabled. Headphone Enable sound output via headphone. OK to activate the function. A check mark indicates enabled. PRESTIGIO P323MW / P373MW... -
Page 34: Tuning Menu
Sources Select the TV signal input source: V+ or V- to select and OK to activate your selection. TV (antenna) or Cable. Search Scan all available channels. V+ to start scanning and EXIT to stop it. PRESTIGIO P323MW / P373MW... -
Page 35: System Menu
V+ or V- to select and OK to activate your selection. enter a password. Test: Allow you to test your password. Lock: Set the input source (No, All, TV, AV (SCART, VGA, YPbPr)) for password protection. PRESTIGIO P323MW / P373MW... -
Page 36: Favourite Menu
TTX-Page 2 Shows the second favourite page’ s teletext information settings of current channel. TTX-Page 3 Shows the third favourite page’s teletext information settings of current channel. TTX-Page 4 Shows the fourth favourite page’s teletext information settings of current channel. PRESTIGIO P323MW / P373MW... -
Page 37: Calibration Menu
PIP Source: select the sub picture input source. Position: select sub picture placement between Top Left, Top Right, Bottom Right, or Bottom Left. Size: set the size of sub picture to Small, Medium, or Large. PIP Sound: allow sub picture sound output. PRESTIGIO P323MW / P373MW... -
Page 38: Chapter 7 Troubleshooting
You can see a picture but hear no sound. * Make sure that the volume is not turned down. * Make sure that the sound is not muted. * Make sure that your audio input source cables are connected securely and correctly. PRESTIGIO P323MW / P373MW... -
Page 39: Appendix A Specifications
MTS/Stereo 15 kg (LCD TV) 3.4 kg (Stand) 1.9 kg (Speaker) Terminals 32” model - Weight 26.5 kg(net) AV Input Video SCART x 2, Composite RCA x 1 (CVBS), Component RCA x 1 (Y Pb Pr) PRESTIGIO P323MW / P373MW... - Page 40 –20 °C to 60 °C (–4 °F to 140 °F) Storage Humidity 10 % to 90 % (no condensation) Regulatory Compliance CE, CB NOTE: Because we continually strive to improve our products we may change specifications and designs without prior notice. PRESTIGIO P323MW / P373MW...
