Bosch PXX875D34E Instruction Manual page 28

Cooking assist functions
en
Setting procedure
Select the appropriate temperature setting from the
table. Place the empty frying pan on the hotplate.
Select the hotplate. Touch the
1.
lights up in the hotplate display.
Within the next 10 seconds, select the required
2.
temperature setting from the settings range.
The function has now been activated.
The temperature symbol
frying temperature is reached. An audible signal will
sound and the temperature symbol will stop flashing.
Once the frying temperature has been reached, add
3.
the fat and then the food to the pan.
Turn the food so that it does not burn.
Note:
Temperature ranges and settings
Cooking functions
Heating, keeping warm
Poaching
Cooking
Cooking in a pressure cooker
Frying with a large amount of oil in the saucepan
Tips for cooking with the cooking functions
Heating/keep-warm function: Frozen products in
■
portions, e.g. spinach. Place the frozen product in
the cookware. Add the quantity of water specified by
the manufacturer. Cover the cookware and select
the 1/70 °C setting. Stir during cooking.
Simmering: Thicken food, e.g. sauces. Bring the
■
food to the boil at the recommended temperature.
Once the food has thickened, simmer at setting 2/
90 °C.
When the signal sounds, keep the food warm at this
setting for the required time.
28
symbol.
é é
é will flash until the
Temperature setting
1/70 ºC
2/90 ºC
3/100 ºC
4/120 ºC
5/170 ºC
Switching off the frying sensor
Select the hotplate and set it to
range. The hotplate switches itself off and the residual
heat indicator appears.
Cooking functions
You can use these functions to heat, simmer or cook
food, or cook it in a pressure cooker or fry it in a
saucepan with sufficient oil at a controlled temperature.
These cooking functions are available for all hotplates.
Benefits
The hotplate only heats up when necessary. This
■
saves energy. Oil or fat will not overheat.
The temperature is continuously monitored. This
prevents the food from spilling over. The
temperature does not need to be readjusted.
A signal will sound once the water or oil has reached
■
the optimum temperature for adding the food. The
table shows if a food needs to be added right at the
start.
Notes
Use pots and pans with a flat base. Do not use pots
■
and pans with a thin or domed base.
Fill the saucepan until its contents are above the
■
silicone patch on the outside of the pan.
Use the frying sensor when frying with a small
■
amount of oil.
Position the cookware in such a way that the
■
temperature sensor is pointing towards the outer
side of the hob.
Do not remove the temperature sensor from the
■
saucepan during cooking. Once the cooking
process has ended, the functions can be selected
for another hotplate.
Remove the temperature sensor from the saucepan
■
after cooking. Caution: The temperature sensor may
be very hot.
Temperature range
60 - 70 ºC
80 - 90 ºC
90 - 100 ºC
110 - 120 ºC
170 - 180 ºC
Boiling: Heat up water with the lid on. It will not boil
■
over. Select temperature setting 3/100 ºC.
Cooking in a pressure cooker function: Follow the
■
manufacturer's recommendations. Continue cooking
for the recommended time once the signal has
sounded. Select temperature setting 4/120 ºC.
Frying with a large amount of oil in the saucepan
■
function: Heat the oil with the lid on. Once the signal
has sounded, take the lid off and add the food.
Select temperature setting 5/170 ºC.
. in the settings
‹ ‹
Suitable for
E.g. soups, punch
E.g. rice, milk
E.g. pasta, vegetables
E.g. chicken, stew.
E.g. doughnuts, meatballs
