Screen systems come with input panels mounted on the side of the cabinet
for easy access and are configured as follows:
Screen 2P and Screen 4P
The Screen 2P and Screen 4P are single input passive only enclosures.
The Full Range input is on a single set of binding posts and the output for
the mid/high horn is available from the XLR connector adjacent (cable
supplied).
Screen 2/4/5B
The Screen 2/4/5B are bi amped driven enclosures. Their main inputs are
on a dual set of binding posts for both Low and High inputs and the output
for the mid/high horn is available from the XLR connector adjacent using
the cable supplied.
Screen 4T and Screen 5
The Screen 4T and Screen 5 are both tri amped enclosures. Their main
inputs are on a triple set of binding posts for Low, Mid and High inputs, the
output for the mid/high horn is available from the NL4 connector adjacent
using the cable supplied.
Note:
Screen 2/4/5
Screen 4/5
5
It is important that loudspeaker systems are used in a safe manner.
Please take some time to review the following points concerning safe use
of Cinema Series Screen 2/4/5 loudspeakers.
Professional loudspeakers are capable of producing extremely high sound
levels and should be used with care. Hearing loss is cumulative and can
result from levels above 90dB if people are exposed for a long period.
Never stand close to loudspeakers driven at high level.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
>
PRINT

INPUT CONNECTIONS

Speaker terminal connections
HF connections White Wire + terminal
Mid connections Brown Wire + terminal

SAFETY FIRST

Martin Audio – CINEMA SERIES
Grey Wire - terminal
Blue Wire - terminal
