Monitor Audio SOUNDFRAME Installation Information page 10

Specifications
Frequency Response
Sensitivity
System Configuration
Driver Compliment:
Nominal Impedance
Maximum SPL (each @1m)
Recommended Amplifier
Requirements (RMS). Watts
Bass Alignment
Power Handling (RMS). Watts
Crossover Frequency
Overall Dimensions (including frame)
(H x W x D)
Weight. Kg (lb)
Finishes
White Lacquer
Black Lacquer
Sound Frame 2
55Hz – 35kHz
86dB
3 way
1 x 6.5" C-CAM
RST II technology.
®
1 x 4" IDC mid-range driver with dual
®
concentric 25mm C-CAM
tweeter.
8 Ohms
106 dBA
25-100
Sealed Box
100
550Hz & 3.3KHz
790 x 240 x 87 mm
(31 x 9 x 3
7/16
7.06 (15.53)
*Matt white cabinet with white high gloss
piano lacquer frame.
*Matt black cabinet with black high gloss
piano lacquer frame.
*Matt white cabinet with white primed frame
(paint-able).
Primer
mid/bass driver with
®
gold dome
®
")
7/16
240mm
FRONT
87.5mm
SIDE
