First-Time Use

Before you begin, ensure that the USB cable is connected, the power cable is connected to
the drive and plugged into an outlet, and the power switch is turned ON.
Each Aegis Padlock DT FIPS is shipped without a preset Personal Identification Number
(PIN) installed on the device. A 7- to 16-digit Admin PIN must first be established before
the drive can be used. This Admin PIN can be used to set any and all of the Admin Mode
Features of the drive, as well as to access its data. Note: PINs can't be repeating or
sequential numbers such as 0123456, 987654321, or 1111111, 2222222, etc.
To Set Up the Admin PIN:
1. Plug device into USB Port. Both the
2. Press + 9 at the same time. The
will blink.
3. Enter the series of numbers that you will use for the Admin PIN and press the
4. Re-enter that same PIN and press the
one second, then replaced by the
5. The drive is now in Admin mode where Admin features can be set (e.g., adding a User.)
6. To exit the Admin mode, press the CANCEL button. The drive will return to the locked
standby state. If no action is taken within 30 seconds, the drive will return to its locked
sleep state.
* GREEN LED will blink if the PIN is accepted; If the PIN is NOT accepted, the
will blink-- return to step 4 to resume the Admin PIN setup process.

LED States and Their Meaning

No LEDs
Blinking
Solid
Blinking
Solid
Blinking
Solid
Solid
Slow Blinking
Solid
Slow Blinking
Alternating
RED
One second of
followed by one
second of
followed by one
second of
BLUE
BLUE
Drive locked, power switch is off, device unplugged
RED Error / incorrect button entry; Mode Not Available;
User PIN Change
RED Locked / Standby state; Awaiting PIN entry
GREEN Button-entry accepted
BLUE / Waiting for New User or Admin PIN to be
GREEN established
BLUE Admin Mode
GREEN Drive unlocked
BLUE Drive unlocked in Lock-Override Mode
GREEN / Drive unlocked in Read-Only Mode
RED
Indicates a mode has been entered that can result
/ BLUE in the deletion of a User or the data on the drive
(depending on the mode chosen.)
Also used when setting Auto-lock feature
RED Self-test mode to ensure all components are ready
and working properly
GREEN
BLUE
BLUE and GREEN
LED will glow steadily and the
button again. The
LED glowing steadily.
LEDs will glow steadily.
GREEN
GREEN LED will illuminate for
LED
button.*
RED LED
4
