Package contents

•
Aegis Padlock DT FIPS
•
AC Adapter
•
USB 3.0 data cable
(backwards compatible
with USB 2.0)
•
Quick Start Guide
Padlock DT
Aegis
Quick Start Guide
NOTE: if you are using the Aegis Configurator to set up your Padlock DT, First
ensure that the device has the "configurable" logo on the belly label. Also, DO NOT
CONFIGURABLE
perform the following Manual Admin and USER PIN SETUP steps below; The Aegis
Configurator will only recognize devices in their factory "out of box" state or devices that have
been completely reset.
Your Aegis Padlock DT is preformatted in NTFS for Windows and is ready for use. For Mac OS
®
formatting, please refer to the Mac OS formatting instructions on the reverse.To access the Aegis
Padlock DT, connect the drive to a power outlet via the AC Adapter and a USB port using the USB
3.0 cable (this cable is also compatible with USB 2.0).
Each Aegis Padlock DT is shipped without a preset Personal Identification Number (PIN.) To prepare
the drive for use, the user must first establish an Admin PIN that is between 6 and 16 digits in length.
PINs cannot contain all consecutive numbers or all the same numbers (e.g. 0123456789, 987654321
or 11111111, 22222222, etc.This Admin PIN is used to set the Padlock DT's various Admin features and
also serves as the first of five User PINS for the Padlock DT's standard operation.
First-Time Use / Admin PIN Setup
1. Plug the Padlock 3 into a USB port and turn power switch to ON.
(BLUE and GREEN LEDs will glow solidly, indicating no Admin PIN has been established.)
2. Press + 9 simultaneously.
GREEN
(BLUE LED will glow solidly and LED will blink.)
3. Enter the PIN to be used as your Admin code and press .
(If PIN is accepted, BLUE LED will turn off momentarily and GREEN LED will blink 3 times by itself,
then will continue blinking as the BLUE LED glows solidly.)*
4. Quickly re-enter that same PIN once more and press
(BLUE LED will turn off momentarily and GREEN LED will illuminate for one second until replaced by
the BLUE LED glowing solidly, indicating that the Admin PIN has been set and the Padlock 3.0 is in
Admin mode, ready to add another User PIN [see reverse] or for setting up features.)
5. To exit the Admin mode, press cancel (RED LED will glow solidly) or wait 30 seconds and Padlock
3.0 will return to standby mode.
6. If no additional users are to be added or Admin features set, Padlock 3.0 setup is now complete and
ready for use.
Adding a New User PIN
There are two ways to establish a User PIN: Admin-generated
while in Admin Mode, and User-generated while Padlock DT is
placed in User Forced Enrollment State.
ADMIN-GENERATED USER PIN
1. Enter the Admin Mode by holding + 0 for five seconds;
With RED LED blinking, enter the Admin PIN and press the
UNLOCK button. The BLUE LED will glow solidly.
2. Press the + 1 buttons together until the BLUE LED
glows solidly and the GREEN LED starts blinking.
3. Enter the User PIN* and press . The GREEN LED will
blink three times by itself, then the BLUE LED will glow
solidly as the GREEN LED continues blinking.
4. Re-enter that same User PIN and press . The GREEN
LED will glow solidly for three seconds verifying that
the User PIN was successfully added, and then will be
replaced by the BLUE LED glowing solidly, indicating that
the drive has returned to the Admin mode.
* If PIN is unacceptable, Red LED will blink 3 times and return to solid BLUE / blinking GREEN LEDs.
