Specifi cations - E241N
Monitor Specifi cations
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort:
DisplayPort Connector:
VGA:
15pin Mini D-sub:
HDMI:
HDMI Connector:
Display Colors
Synchronization Range
Viewing Angle
Resolutions Supported (Some systems may
not support all modes listed).
Active Display Area
Landscape: Horiz.:
Portrait: Horiz.:
AUDIO
AUDIO Input:
STEREO Mini Jack:
DisplayPort Connector:
HDMI Connector:
Headphone Output: STEREO Mini Jack:
Speakers
Practical Audio Output:
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current fl at panel technologies when displaying non-native resolutions full screen. In fl at panel technologies, each dot on the screen is actually one
pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifi cations are subject to change without notice.
MultiSync E241N Monitor
Diagonal:
60.47 cm/23.8 inches
60.47 cm/23.8 inches
1920 x 1080
Digital RGB
Analog RGB
Sync
Digital YUV
Digital RGB
16,777,216
Horizontal:
31.5 kHz to 81.1 kHz
Vertical:
56 Hz to 75 Hz
Left/Right:
±89° (CR > 10)
Up/Down:
±89° (CR > 10)
720 x 400*
1
: VGA text
1
640 x 480*
at 60 Hz to 75 Hz
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
1
at 75 Hz
1
1024 x 768*
at 60 Hz to 75 Hz
1152 x 870*
1
at 75 Hz
1
1280 x 1024*
at 60 Hz to 75 Hz
1
1400 x 1050*
at 60 Hz to 75 Hz
1440 x 900*
1
at 60 Hz
1920 x 1080 at 60 Hz........................................... resolution for optimal display performance.
527.04 mm/20.7 inches
Vert.:
296.46 mm/11.7 inches
296.46 mm/11.7 inches
Vert.:
527.04 mm/20.7 inches
Analog Audio
Digital Audio
Digital Audio
1.0 W + 1.0 W
100 - 240 V ~ 50/60 Hz
0.50 - 0.30 A
Landscape:
538.6 mm (W) x 373.9 - 483.9 mm (H) x 213.9 mm (D)
21.2 inches (W) x 14.7 - 19.1 inches (H) x 8.4 inches (D)
Portrait:
319.4 mm (W) x 555.1 - 593.2 mm (H) x 213.9 mm (D)
12.6 inches (W) x 21.9 - 23.4 inches (H) x 8.4 inches (D)
110 mm / 4.3 inches (Landscape orientation)
38.1 mm / 1.5 inches (Portrait orientation)
5.5 kg (12.1 lbs) (with stand)
5°C to 35°C/41°F to 95°F
Humidity:
20% to 80%
Altitude:
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin fi lm transistor (TFT) liquid crystal
display (LCD); 0.2745 mm dot pitch; 250 cd/m
luminance; 1000:1 contrast ratio (typical), (5000:1
Contrast ratio, DV MODE ON).
DisplayPort Complies with Standard V1.1a,
applicable to HDCP
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
HDMI
Depends on display card used.
Automatically
Automatically
NEC DISPLAY SOLUTIONS cites recommended
Stereo L/R 1.0 Vrms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Impedance 32 Ohm
English-17
