– Microwave ovens – minimum 20 feet away from
VAPR VUE generator and wireless footswitch
– Other VAPR VUE Wireless footswitches – no
minimum distance from VAPR VUE generator
and wireless footswitch
Battery Replacement Transmitter
A
Name
A
B
C
D
E
F
G

BATTERY REPLACEMENT

1. Turn the slotted screw (C) ¼ turn counter-clockwise.
2. Remove the battery cover (B) by gently prying with a
flat tip device in the recessed area near the screw.
Be careful to not damage the O-ring seal (D).
3. Remove and properly dispose of old batteries.
B
2X Locking Tabs
Battery Cover
Slotted drive ¼ turn fastener
O-Ring seal
3X "AA" Alkaline batteries
Recessed area for cover removal. Gently
pry with flat tip device to remove cover
3X Battery polarity indicator on bottom
face of holder
Description
6
C
D
E
F
G
