interface), the sign "Recording" will appear on the screen in 30 seconds, then the screen will be
automatically shut down. If you push the button, the sign "Recording" will appear on the screen,
and then the screen will be automatically shut down again; if you press and hold the button, the
device will return to the former interface.
e. If you turn the data storage function on, the previous data stored will be automatically removed.
f. To save power during the state of data storage, the screen is automatically shut down and the
pulse sound indication is turned off.
g. When the storage space is full, the screen displays the warning "Memory is full", and shuts down
after a few seconds. The warning will still be displayed the next time the device is turned on for
the purpose of alerting the user. If you press the button again, it will enter the measuring
interface.
E. Uploading data to a computer after recording
a. Connect the device to a computer via the data line which is affiliated with the device. Double click
the "SpO Review" icon to open the program. Click the 'New Session' icon in the software,
2
enter the patient data and then click 'OK'. The Software will display "device connected, waiting
for data".
b. Press the power button to enter the "Settings Menu" and then Click the power button to select
"Upload". Press the power button to select "on". The data will be transferred to your computer.
c. The users cannot upload stored data to a computer while the device is in the state of storing.
d. You cannot cancel the upload of stored data. When the upload is finished, the menu choice bar
will move to "Exit" automatically.
F. Exit the main menu
Select "EXIT" to exit the Main Menu.
G. Charging
There are two charging methods:
a) Connect the device to a computer via data line. The device will begin charging.
b) Connect the device to a power supply via a power adapter. The device will begin charging.
When the device is charging, the indication light is orange. When the battery is full, the light turns green.
If the alarm function is on, the device will produce a high-priority alarm signal when the
battery is low. An intermittent alarm will go off and the battery icon will flash red.
High-priority alarm indicates that immediate operator response is required.

6.2. Attention for Operation

A. Please check the device before use to ensure that it is working normally.
B. The finger should be placed in the proper position or else it may result in inaccurate
measurement (see the illustration in Figure 4).
C. The SpO sensor should not be used at a location or limb tied with an arterial canal or blood
2
TORONTEK-E400 Pulse Oximeter
Figure 9
