DISPLAY FEATURES
The displays (one for each output) are graphic LCDs, backlit by white LEDs; contrast is software-
controlled and can be adjusted from the keyboard.
The default status displays show the VOLTS (5 digits) and AMPS (4 digits) in 12mm high
characters, plus output range and status. At other times, for example during store or recall of
instrument set-ups, the displays show up to 7 lines of information, instructions, or prompts.
INTERFACES (QPX600DP only)
Full digital remote control facilities are available through the RS232, LAN, USB and GPIB
interfaces. Setting and readback resolutions are the same as for the Output and Meter
specifications respectively.
RS232:
USB:
LAN:
GPIB:
Remote Command
Processing Time:
GENERAL
AC Input:
Power Consumption:
Operating Range:
Storage Range:
Environmental:
Store/Recall:
Safety:
EMC:
Size:
Weight:
Options:
4
Standard 9-pin D-connector. Baud rate 9600.
Standard USB 2.0 hardware connection.
Auto speed detect(10/100MHz), Auto MDIX.
LXI V1.2, Class C compliant.
Conforms with IEEE488.1 and IEEE488.2.
Typically <100ms between receiving the command terminator for a
step voltage change at the instrument and the output voltage
beginning to change.
115V – 240V AC ± 10%, 50/60Hz.
Installation Category II.
1600VA max.
+5ºC to +40ºC, 20% to 80% RH.
−40ºC to + 70ºC.
Indoor use at altitudes up to 2000m, Pollution Degree 2.
Up to 10 set-ups can be saved and recalled via the keyboard or
remote interfaces.
Complies with EN61010-1.
Complies with EN61326.
130mm H (3U) x 356mm W x 413mm D
9.2kg
19-inch rack kit.
