CUT OUT TEMPLATE FOR Di 3.5R
PART NUMBER 5875A101
INSTALLATION OF THIS PRODUCT MUST FOLLOW ALL
LOCAL
&
STATE BUILDING CODES
DO NOT PAINT GRILLE WITH ROLLER OR BRUSH,
SEE MANUAL FOR PAINTING DIRECTIONS
FOR A PRECISE CUT USE A 3 3/4" DIAMETER HOLE SAW TO CUT HOLE
TOTAL DIAMETER OF CUTOUT: 3 3/4" [95.5mm]
.....
----------------------------------------------------------
...
CLEARANCES REQUIRED FOR INSTALLATION:
ALLOW AT LEAST 7/16" [llmm] FROM EDGE OF CUTOUT TO THE NEAREST
OBSTRUCTION BOTH INSIDE AND OUTSIDE OF THE MOUNTING SURFACE
ADDITIONAL CLEARANCE
TOTALLING 1 1/8" [28.5mm] FROM
EDGE OF CUTOUT REQUIRED INSIDE MOUNTING SURFACE
ON 1 SIDE TO PROVIDE CLEARANCE FOR CROSS-OVER
DO NOT CUT MOUNTING HOLE OVER·SIZED
'BEFORE CUTTING OPENING FOR SPEAKER,
CUTTING A TEST HOLE TO CHECK FOR OBSTRUCTIONS
AND CONSTRUCTION DIMENSIONS IS ADVISED
TRACE AROUND EDGE,
THEN CUT ALONG LINE
\
