CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA C22.2 No-46 / UL 1278 CSA STANDARD
EF39HD
ELECTRIC FIREPLACE
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
SAFETY INFORMATION
WARNING
!
If the information in these instructions are not
followed exactly, an electrical shock or fire
may result causing property damage, personal
injury or loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada (705)721-1212 fax(705)722-6031
$10.00
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE
OPERATION INSTRUCTIONS
www.napoleon replaces.com ask@napoleon.on.ca
For customer service inquiries, please call 1-866-592-6667
(9:00am - 5:00pm PST)
INSTALLATION AND
1
W415-0752 / 12.12.08
W415-0752 / 12.12.08
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Napoleon EF39HD
Summary of Contents for Napoleon EF39HD
-
Page 1: Safety Information
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada (705)721-1212 fax(705)722-6031 www.napoleon replaces.com ask@napoleon.on.ca For customer service inquiries, please call 1-866-592-6667 (9:00am - 5:00pm PST) W415-0752 / 12.12.08... -
Page 2: Table Of Contents
table of contents iNTrOduCTiON Warranty dimensions listing approvals general instructions lOCaTiNg appliaNCE unpacking and testing appliance grounding appliance iNsTallaTiON minimum clearance to combustibles installing the appliance glass ember installation glass front installation fiNishiNg minimum mantel clearances OpEraTiNg iNsTruCTiONs main poWer sWitch operating by remote control maiNTENaNCE replacing the flame generation light bulbs... -
Page 3: Warranty
This warranty defines the obligations and liability of NAPOLEON® with respect to the NAPOLEON® electric fireplace and any other warranties expressed or implied with respect to this product, its components or accessories are excluded. NAPOLEON® neither assumes, nor authorizes any third party to assume, on its behalf, any other liabilities with respect to the sale of this product. -
Page 4: Listing Approvals
This appliance has been tested in accordance with the CSA Standards for fixed and location-dedicated electric room appliances in the united states and canada. if you need assistance during installation, please contact your local dealer. model Number ef39hd NOTE: This appliance must be electrically wired and description Wall-mount appliance... -
Page 5: General Instructions
general instructions WARNING read these instructions completely before beginning installation. failure to follow them could cause a appliance malfunction resulting in serious injury and/or property damage. all electric appliances have hot and arcing or sparking parts inside. do not use it in areas where gasoline, paint or flammable liquids are present. - Page 6 When using electric appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. read all instructions before using this appliance. 2. this appliance is hot when in use. to avoid burns, do not let bare skin touch hot surfaces. if provided, use handles when moving this appliance.
-
Page 7: Unpacking And Testing Appliance
2.0 locating appliance WARNING Due to high temperatures, this electric appliance should be located out of traffic. Keep combustible materials such as furniture, pillows, bedding, papers, clothes and curtains at least 36" from the front of the appliance. Never locate this electric appliance where it may fall into a bathtub or other water container. Wear safety gloves and safety glasses for protection during installation and maintenance. -
Page 8: Installation
3.0 installation WARNING RISK OF FIRE! The power cord must not be pinched against a sharp edge. Secure cord to avoid trip- ping or snagging to reduce the risk of fire, electric shock or personal injury. Do not run cord under carpeting. -
Page 9: Glass Ember Installation
5. mark out location, then mount the bracket onto the Screws wall using the four supplied screws. ensure the top slots measurement from the floor is 1.250” lower then the top back edge measured earlier. this bracket must have the hooks facing upward and be level. NOTE: it is strongly recommended that the mounting bracket be screwed into the wall studs where possible. -
Page 10: Glass Front Installation
glass front installation WARNING do not over tighten the bolts. Over tightening the bolts may result in glass breakage. it is recommended that two people install this glass front onto the appliance, Wear safety glasses and gloves when handling glass. 1. -
Page 11: Operating Instructions
5.0 operating instructions once the appliance has been plugged in to a grounded electrical outlet, it is ready to operate. NOTE: Ensure the house circuit breakers for the power supply are turned on. main power switch the main power switch is located on the bottom of the appliance as illustrated. the "|"... - Page 12 6.0 maintenance WARNING prEparaTiON fOr maiNTENaNCE always disconnect the power and allow the electric appliance to cool before performing any clean- ing, maintenance or relocation of this electric appliance. Turn controls to Off and remove plug from outlet or turn off the house circuit breaker to electric appliance receptacle. Do not install replacement bulbs that exceed specified maximum watts.
-
Page 13: Replacing The Flame Generation Light Bulbs
replacing the flame generation light bulbs WARNING Remove the fireplace from the wall and turn off electrical power before servicing the appliance. 1. remove the 6 screws on the back plate of the Flame Generation Bulb Location appliance near the bottom. open back plate from the top. -
Page 14: Replacing The Ember Bed Light Bulbs
replacing the ember bed light bulbs Ember Bed Bulb Replacement Ember Bed Bulb Replacement Ember Bed Bulb Replacement Ember Bed Bulb Replacement figurE 6.2.2 Ember Bed Bulb Replacement Ember Bed Bulb Replacement 2 screws 2 screws figurE 6.2.1 2 screws Right Left Right... -
Page 15: Replacement Parts
● Finish * IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER. for aftermarket sales and service please call 1-866-592-6667 components rEf NO. Ef39hd dEsCripTiON r-21 remote control transmitter dQ002-011 remote receiver JQ-fageti-19... -
Page 16: Troubleshooting
8.0 troubleshooting WARNING Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. OBsErvEd prOBlEm pOssiBlE CausE rEmEdy Dim or no flame 1. bulb(s) are burnt out 1. Inspect the bulbs inside the flame generation cylinder drum and replace them if necessary ember bed is not glowing or dimming...
