The desired temperature is displayed opposite the
chosen arrow .
The temperature is the temperature measured in the
bowl .
The power or heat temperature can be adjusted
during operations.
If you do not wish to use the heat function, select the
2 dashes (—— °C) on the heat line.
2. Speed Functions:
• Speed variator from 80 to 3,500 rpm.
Once you have pressed the speed switch, the rotary
dial will allow you to choose the desired speed.
Functions Speeds
100 to 500 rpm or
Blend
R-Mix -100 to -500 rpm
Cut 600 to 2,000 rpm
Mix
2,100 to 3,000 rpm
Emulsify
3,000 to 3,500 rpm
• The R-Mix function (blend function: the blade turns
in the opposite direction so as not to cut the food)
can be accessed between –100 rpm and –500 rpm.
To obtain this, you need to turn the rotary dial to
minus (–). If the motor is running, it will stop when
reaching 0 rpm. You will need to restart the machine
once the speed has been chosen.
• Intermittent Speed Function: the blade rotates a
few times every 2 seconds.
o obtain this, you need to turn the rotary dial to
minus (–) until you reach the display
Benefit: This function maintains the temperature of
the preparation-in-progress without changing the
texture. It also prevents the motor from overheating
on low speed if the bowl is very full.
• Turbo Function:
This function will enable you to reach a speed of
4,500 rpm. To obtain this, you need to press on the
Turbo/Pulse switch for the required run time.
The Turbo function can only be used when the
machine is already running.
• Pulse Function:
The high-precision pulse function gives you better
control over processing. Turn the button to adjust the
pulse speed.
You can only use the pulse function from standstill.
3. Timer Function:
1 - Countdown Mode
By pressing the switch , you will set the run
time of the appliance with the rotary dial.
At the end of the run time, a short bell will ring
by default.
You can choose to activate the long bell option
to set a long ring alert by pressing twice on
the Timer button .
2 - Timer Mode
A timer records the run time of the appliance by
default.
3 - Differed Mode
By pressing 2 seconds on the Timer switch
the following display appears on your screen
.
You will set the desired run time of the appliance
using the rotary dial once the chosen temperature
is reached.
This mode will automatically deactivate after use
and the indicator will disappear.
Benefit: This mode enables you to activate the
Timer only once the chosen cooking temperature
is reached. You can thus program the cooking
time independently of the start temperature and
of the quantity of food.

• OPERATIONS:

The Pulse, Run and Stop switches send instructions to
the machine. They are present on all ROBOT-COUPE
appliances.
They will carry out what appears on the display
panel. (What has been « programmed »).
Black switch Green switch
Turbo Pulse Run
Pressing 2 seconds on the Red Stop switch will reset
the settings to the initial configuration. (connect the
appliance).

• PROGRAMMING:

- Use a programme:
Go to the Programme function
programme number using the rotary dial.
, Turn on your appliance to the chosen programme.
.
Red switch
Stop
+
, choose the
