ASSEMBLY

BEFORE FIRST USE

Before using your food processor, become familiar with all the parts.
Wash the processing bowl, processing lid and other attachments in warm,
soapy water. Rinse and dry thoroughly. (Refer to Care & Cleaning).
1. Place the processing bowl handle in line with the ALIGN HANDLE
graphic on the motor base (see fig. 1 ).
2. Turn the handle clockwise until aligns with the TURN TO LOCK
graphic (see fig. 2 ).
3. The spindle is required when using all discs. Position the spindle over
the coupling in the centre of the processing bowl. Then position your
chosen cutting attachment over it. Push down firmly until fitted correctly
(Please note that these discs only fit the larger processing bowl)
(see fig. 3 ).
4. Place lid onto the processing bowl so that the ALIGN/LOCK graphics
on the lid and handle align (see fig. 4 ). To LOCK the lid, hold the
chute and turn clockwise so that the handle parts align. Locking the lid
correctly will engage the interlocking safety catch on the handle,
and allow the motor to run.
NOTE
• If using the mini processing blade, ensure the mini processing bowl is
assembled into the main bowl first.
• Some stiff mixtures, such as dough may cause the processing blade to
rotate more slowly than normal. If this happens, do not process for longer
than 1 minute.
• Do not fill bowl above marked liquid levels (shredding). Always add drier
or thicker ingredients to the processing bowl prior to adding fluids.
OVER LOAD PROTECTION SYSTEM
• If the motor overloads, the food processor will go to STANDBY mode and
OVERLOAD icon in the LCD starts to flash. The food processor can still
be switched off by pressing the POWER/OFF button. To operate the food
processor again, allow the machine to cool for approx. 30 minutes.
• If the blades or discs should jam while processing, ensure the
POWER/OFF button is pressed to switch the motor off. Switch off the
power outlet. Remove the processing lid and adjust any food wedged
between the blade and the bowl or in the disc. Replace the lid and
proceed as normal. If this occurs again, the processing bowl may be
overloaded, so remove some of the food and process in smaller batches.
NOTE
The food processor is designed so the motor will not operate without
the processing bowl and lid correctly locked into position and the pusher
inserted into the feed chute. In the event that the food processor starts
without the lid correctly locked into position, immediately disconnect
at the power outlet and contact Sage™ by Heston Blumenthal
Customer Service.
6

OPERATION

CHOPPING WITH THE QUAD

• The micro-serrated Quad
consistency required, from coarsely chopped to minced.
• Avoid over-processing by checking the consistency frequently. For many
tasks, we recommend using the PULSE button, as it may only take a few
seconds to fully process food to your desired consistency.
• If necessary, turn the POWER off and use a spatula to scrape down the
sides of the bowl to encourage even processing.
RAW VEGETABLES, FRUIT AND COOKED MEATS
Trim and cut food into 2.5cm cubes. Process no more than 4 cups at a time
using the PULSE button at 1–2 second intervals until chopped to desired
size or consistency.
RAW MEAT, CHICKEN AND FISH
• Trim excess fat and cut food into 2.5cm cubes. Ensure all bones are
removed. Chill well in freezer until firm as this will help to cut through the
food more readily.
• Process no more than 600g of raw meat at a time. At this capacity the
motor should run for no more than 30 seconds at a time.
• Use a combination of the START | PAUSE and the PULSE button until
chopped or minced to the desired consistency.
GARLIC, CHILLI AND GINGER
• Peel garlic cloves and process them whole. Leave chillies whole,
or remove seeds for milder chilli. Peel and cut ginger into 2.5cm cubes.
• For other solid herbs like lemongrass or galangal, peel and cut into cubes
or pieces between 1 and 2cm in size.
• Size should be made smaller for harder or more dense herbs.
• Process using the PULSE button at 1–2 second intervals until chopped
to the desired consistency.
• If adding garlic, chilli or ginger to other ingredients, drop whole pieces
down the small feed chute while the motor is running.
LEAFY HERBS
Wash and dry herbs thoroughly. Remove any coarse stems.
Process no more than 2 bunches of herbs (approx. 4 cups) at a time using
the PULSE button at 1–2 second intervals until chopped to the desired
consistency.
NUTS
Process no more than 4 cups of shelled nuts at a time using the PULSE
button at 1–2 second intervals until chopped to the desired consistency.
NUT BUTTERS
® • Process no more than 4 cups of shelled roasted nuts at a time using the
START | PAUSE button until chopped to the desired consistency.
• The volume of nuts reduces after processing, for example 2 cups of nuts
will make around 1 cup of nut butter.
• Natural nut butter (without using stabilisers) will separate on standing,
and needs to be stirred before use.
• For smoother nut butter, add a little vegetable oil. This can improve the
texture of nuts with lower oil content, like roasted almonds.
DRIED FRUIT
• Dried fruit can be sticky, and may stick to the blades during processing.
We recommend putting dried fruit in the freezer for about 10 minutes
before processing. Process no more than 2 cups at a time using the
PULSE button at 1–2 second intervals until chopped to the desired
consistency.
BLADE
®
blade chops raw and cooked food to the
®
