Aviation Design sukhoi su-35 Assembly Manual

For 2 amt mercury or 2 jet cat p 120
Hide thumbs

Advertisement

Table of Contents

SUKHOI
Assembly Manual
ZI le chenet, 91490 Milly La Foret, FRANCE
AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com
SU-35
SU-37
for 2 AMT Mercury
or 2 Jet CAT P 120
AVIATION Design
AVIATION Design
AVIATION Design
AVIATION Design
Tel : 33 1 64 98 93 93
Fax : 33 1 64 98 93 88
E-mail :
aviation.design@wanadoo.fr
www.adjets.com
Version 01/09/2009
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the sukhoi su-35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aviation Design sukhoi su-35

Summary of Contents for Aviation Design sukhoi su-35

  • Page 1 Fax : 33 1 64 98 93 88 E-mail : aviation.design@wanadoo.fr www.adjets.com Version 01/09/2009 AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 2: Kit Features

    - Clear formed canopy. - vacuum parts - instructions in English and plan. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 3: Landing Gear

    Air brake : Include special air cylinders, 4 way valve, tubing, connectors, AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 4: Gluing Techniques

    All the plywood formers should be fitted with cyano adhesive and then glued with epoxy and glass fiber tape. All other parts should be glued with epoxy. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 5 Make 2 fence in the front gear door according to the engraved panel line Glues with CA the plastic vacuum parts in the front gear door AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 6 Glue this tape with epoxy overlapping all the formers and the fuselage. Let them dry overnight. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 7 Screw the gear on C10 with 2x M3 x 12 alen screw These 2 plywoods will be glued under the skin AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 8 Check to glue very strongly C14 in the fuselage against the main fraime Let them dry overnight. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 9 Check that they can move without problem. Glue C20 with CA for the moment. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 10: Fin Assembly

    Drill a hole through the aluminium joining tube to secure the fin Insert a screw to secure the fin AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 11 Connect the servo to the carbon control hon with the 2 M4 aluminium ball link and the M4 threated rod AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 12 Fit the air brake on the fuselage with the piano wire Connect the air cylinder to the control horn with the aluminium link AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 13: Air Intakes

    Put some clothes pegs all around the intake leading eadge during drying. Let them dry overnight. Trim all the leading edge. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 14 Secure the hinges with 2 parker screw and plywood reinforcement C29 inside AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 15 Cut the rear gear door according to the engraved panel line. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 16 Wing tip missile rails : Fit the wing tip missile rails with 2 parker screws 3x20 AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 17 Fit the steering control arm + the oleo legs on the retracts Glue the ABS cover on the wheel hole AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 18: Fuel Tanks

    Glue with silicon glue the 2 upper tanks just in front of the main tanks AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 19: Assemble The Fuselage

    Glue 6 x 3 mm plywood reinforcement on the hole location. Screw the 2 parts with 6 parker screws AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 20 Insert the hatch latch in the fuselage to secure the canopy frame on the fusleage. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 21 Glue the 2 vaccum parts together with CA Glue the platic parts on the vaccum parts according to the photos. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 22 Cut the vaccum part according to the photo Glue them on the air intake with CA AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 23 AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 24 Drill a 2 mm hole in the fuelage. Glue the 2 pitot with CA. Secure it inside with epoxy. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 25: Ventral Fins

    Drill 4 x 2 mm hole and insert the parker screw in the wood. Drill a hole for all the tubing and engine connector. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...

  • Page 26: Exhaust Tube

    Connect all the retract tubing according the manual to the air valve. Connect all radio wire AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 27 300 KPH. It is your responsibility to operate it safely. Specifications may change without notice. AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 28 AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 29 AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 30 AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
  • Page 31 AVIATION DESIGN - ZI le Chenet - 91490 MILLY LA FORET – FRANCE - Tel : int+ 33 1 64 98 93 93 - aviation.design@wanadoo.fr – www.adjets.com...
