PART LIST—Model No. PFEX71060
Key
No.
Qty.
Description
1
1
Frame
2
1
Seat Frame
3
1
Idler Bracket
4
1
Idler Wheel
5
1
Right Handlebar
6
1
Left Handlebar
7
1
Resistance Knob
8
1
Resistance Dial Assembly
9
1
Belt
10
2
Handlebar Housing
11
1
Star Washer
12
2
Friction Pad
13
1
Long Carriage Bolt
14
1
Crank
15
1
Pulley
16*
1
Crank Bearing Assembly
17
1
M8 Nut
18
2
Washer
19
1
Axle Bushing
20
2
Star Washer
21
2
Seat Frame Endcap
22
1
Flywheel
23
2
M10 Flat Washer
24
1
Left Side Shield
25
1
Right Side Shield
26
9
M4 x 8mm Screw
27
5
Tree Fastener
28
1
Flywheel Axle
29
1
Console
30
1
Left Pedal Strap
31
1
Right Pedal Strap
32
1
Idler Pivot Bolt
33
2
Wheel Hub
Note: "#" indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of this manual for information about ordering replacement parts.
R0797A
Key
No.
Qty.
Description
34
2
Wheel
35
2
Wheel Bushing
36
1
Lock Knob
37
3
3/8" Nylon Locknut
38
4
M8 Nylon Locknut
39
1
Extension Spring
40
1
M5 Screw
41
2
Grip
42
2
Stabilizer Endcap
43
4
Handlebar Endcap
44
1
Seat Frame Bushing
45
1
Frame Bushing
46
2
Seat Spacer
47
1
Right Pedal w/Strap
48
1
Left Pedal w/Strap
49
1
Idler Spring
50
1
Reed Switch Wire
51
1
Push Nut
52
2
M8 x 60mm Bolt
53
1
Seat
54
1
Backrest
55
4
Seat Screw
56
4
1/4" x 5/8" Screw
57
2
Wheel Screw
58
1
Seat Bracket
59
2
Seat Bracket Bolt
60
4
1/4" Flat Washer
61
1
Magnet Bracket
62
4
1/4" x 9/16" Screw
63
1
Backrest Cover
64
1
Flywheel Spacer
#
1
Tool Set
#
1
User's Manual
14
BELANGRIJKE VOORZORGSMAATREGELEN
Om het risico van verwonding bij personen te voorkomen, dient U de volgende voorzorgsmaatrege-
len en informatie voor gebruik van de PROFORM 770S door te lezen.
1. Read all instructions in this manual before
using the 990S.
2. It is the responsibility of the owner to ens-
ure that all users of the 990S are
adequately informed of all precautions.
3. Use the 990S indoors, on a level surface.
Keep the 990S away from moisture and
dust. Place a mat under the 990S to protect
the floor or carpet.
4. Inspect and tighten all parts regularly.
Replace any worn parts immediately.
5. Keep children under age 12 and pets away
from the 990S at all times.
6. The 990S should not be used by persons
weighing more than 250 pounds.
WARNING: Before beginning this or any exercise program, consult your physician. This is espe-
cially important for persons over the age of 35 or persons with pre-existing health problems. Read
all instructions before using. ICON assumes no responsibility for personal injury or property dama-
ge sustained by or through the use of this product.
The decal shown at the right
has been placed on the 990S. If
the decal is missing, or if it is
Do not allow children on or
not legible, please call our plea-
around machine.
se call our Customer Service
Department at 0345-089009 to
Keep hands and feet away
order a free replacement decal.
from moving parts and contact
Apply the decal in the location
points.
shown.
Read owner's manual and
follow instructions.
7. Wear appropriate clothing when exercising;
do not wear loose clothing that could beco-
me caught on the 990S.
8. Always wear athletic shoes when using the
990S.
9. Always keep your back straight when using
the 990S. Do not arch your back.
10. If you feel pain or dizziness at any time
while exercising, stop immediately and
begin cooling down.
11. Use the 990S only as described in this
manual.
12. The 990S is intended for in-home use only.
Do not use the 990S in a commercial, rental,
or institutional setting.
