- Page 1 Vehicle Installation Guide IBR900/950/1100/1150 4/10/17 COR Series Router IBR900/IBR950 AND IBR1100/IBR1150 Vehicle Installation Guide ©2017 Cradlepoint. All Rights Reserved. +1.855.813.3385 cradlepoint.com...
- Page 2 IBR900 POWER & GPIO The Cradlepoint COR IBR900/950 and IBR1100/1150 include a two meter, 22 AWG direct wire power and GPIO cable (includes ESD-protected general input and output pins): This diagram shows the connector pinout. This is the view into the router (or the rear view of the cable...
- Page 3 IBR900/950/1100/1150 4/10/17 The wire colors shown are for the power/GPIO cable that is included with the COR IBR900/950 and IBR1100/1150 or available as an accessory. Other wiring setups may have different colors. If you need a power/GPIO cable that is longer than two meters, we recommend the following wire gauges (AWG): •...
- Page 4 IBR900/950/1100/1150 4/10/17 ANTENNAS Antennas are not included in the product package because of the diverse needs of customers. The COR IBR900/950 and IBR1100/1150 have two connectors for 3G/4G modem antennas (SMA) and one connector for GPS (SMA): LEDs 3G/4G Antenna...
- Page 5 • For sheet metal installation, use #8 self-drilling screws. • For tapped holes, use M4 machine screws. To mount the COR IBR900/950 or IBR1100/1150 with the optional Dual-Modem Dock, refer to the Dual-Modem Dock Quick Start Guide. ©2017 Cradlepoint. All Rights Reserved.
