SERVICE MANUAL
Model : FR-291
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-291 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo FR-291

Summary of Contents for Daewoo FR-291

  • Page 1 SERVICE MANUAL Model : FR-291...

  • Page 2: Major Accessories

    1. SPECIFICATION 1. MAJOR ACCESSORIES NAME Q’TY ICING CASE FREEZER ROOM FREEZER SHELF FREEZER POCKET REF. SHELF COVER VEGETB CASE VEGETABLE CASE REFRIGERATOR EGG CASE ROOM EGG POCKET UTILITY POCKET JUMBO POCKET BOTTLE POCKET 2. QUALITY SPECIFICATION 표시 구분 표시 내용 FR-290 FREEZER GROSS...
  • Page 3 2. NAME OF FARTS...

  • Page 4: Air Flow Diagram

    3. AIR FLOW DIAGRAM...

  • Page 5: Refrigerant Cycle Diagram

    4. REFRIGERANT CYCLE DIAGRAM...

  • Page 6: Machine Room View And Part List

    5. MACHINE ROOM VIEW AND PART LIST...

  • Page 7: Wire Diagram

    6. WIRE DIAGRAM & SOLID WIRE DIAGRAM 1) WIRE DIAGRAM...
  • Page 8 2) SOLID WIRE DIAGRAM...

  • Page 9: Main Components

    7. MAIN COMPONENTS 1. COMPRESSOR FR – 290 MODEL YX58LHP5 STARTING TYPE RSCR VOLTAGE 230V / 50Hz MAIN COIL RESISTANCE 23.72Ω SUB COIL RESISTANCE 17.89Ω 2. RELAY FR – 290 MODEL 4TM149SHBYY-52 RESISTANCE 22Ω MAX. VOLTAGE 320V MIN VOLTAGE OL CURRENT 4.0A 3.

  • Page 10: Power Cord

    4. LAMP FR – 290 VOLTAGE AC 240V / 15W 5. POWER CORD FR – 290 TYPE 3x0.75 ㎟ LENGTH 1.95m 6. TEMPERATURE FUSE FR – 290 VOLTAGE 250V CURRENT ℃ WORKING TEMP. 7. Bi-METAL FR – 290 MODEL PST - 3 ±...

  • Page 11: Defrost Heater

    8. DEFROST HEATER FR – 290 RATING AC 230V / 190W Ω RESISTANCE 9. FAN MOTOR FR – 290 MODEL DAI-6122-DESFD TYPE SHADED POLE RATING 230V/50HZ INPUT 5.0W POLE 2 POLE 2200 ± 150 rpm 10. R-THERMOSTAT FR – 290 MODEL GNF-175D-01F RATING...
  • Page 12 12. CONTL BOX HEATER FR – 290 RATING AC 220V / 4W Ω RESISTANCE 12100...
  • Page 13 8. EXPLODED VIEW & PART LIST...
  • Page 14 PART CODE PART NAME Q’TY REAMRK 3010815700 CABINET URT AS 3011755200 DOOR S/W AS WDS001C-01 3012924600 HINGE *T AS 3016000301 SPECIAL BOLT M5 x L14 3001400000 COVER *T HI 3012924500 HINGE *M AS 3016004000 SPECIAL BOLT M6 x L10 3012924700 HINGE *U AS 7650602511 BOLT HEX...
  • Page 15 3015511000 WINDOW R GPPS 3011187300 CASE ICING 3017843700 SHELF F GPPS 3017843600 SHELF R GPPS 3001400700 COVER VEGETB CASE GPPS 3011187600 CASE VEGETB GPPS 3019027900 POCKET F GPPS 3012319500 GASKET F DR AS PVC-S+MAGNET 3011766900 DOOR F URT AS 3011187200 CASE EGG 3019027800 POCKET EGG...

  • Page 16: Methods Of Exchanging Main Parts

    9. Methods of exchanging main parts. 1. F LOUVER PART - Remove the screw cap, and unscrew the fixing screw(2EA). Pull the louver forward, grasping at the fan cover and upper corner of louver. - Disassemble fan motor harness and remove Louver As..
  • Page 17 2. EVAPORATOR PART - Pull the suction pipe and capi. Tube forward, with care not to bend the pipes sharply. - Hold up evaporator and pull it forward. - Remove the evaporator pad. - To remove defrost heater, cut the clamp cable first, disassemble the harness then pull down the heater.
  • Page 18 - To exchange the Bi-Metal, first cut the clamp cable then disassemble the harness. - Extract the Temp. Fuse in the evaporator then disassemble the harness . - The new Temp. Fuse should be located in the same position in the evaporator. 3.
  • Page 19 - Unscrew the fixing screw(1EA) . - Pull down the control box, then disassemble the harness. - Remove the lamp cover with screwdriver etc. pushing the front hooker part of the cover then lift up the cover. - Unscrew the fixing screw of the lamp socket.
  • Page 20 - Pull the lamp forward, then disassemble the connector. - The assembling procedure of new lamp is the reverse of disassemble steps. 4. DOOR SWITCH PART - In removing the door switch, push the door switch left, insert a pointed rods as screw- driver in the right gap, and push the rod left and pull the door switch forward.
