Service Manual
Refrigerator
Model: FR-260
Caution

: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : FR2600000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-260 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daewoo FR-260

  • Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.
  • Page 2: Table Of Contents

    CONTENTS 1. Specification 2. External view 3. Name of parts 4. Air flow diagram 5. Methods of exchanging main parts 6. Trouble shooting procedure 7. Cycle refare flow chart 8. How to judge cooling cycle problem 9. Refrigrant cycle diagram 10.
  • Page 3: Specification

    1. SPECIFCATION Model Name FR-260 R-134a Refirgerant R-12 105g Cooling System Fan Cooling Convection Type Refirgeration System Air Forced Convection Defrost System Forced Fin-Evaporator Type Defrost Operation Automatic Start & Stop Cold Control Adjustable Dial Freezer (L) 56/65 Capacity Refrigertor (L)
  • Page 4: Name Of Parts

    3. NAME OF PARTS FR-260...
  • Page 5: Air Flow Diagram

    4. AIR FLOW DIAGRAM FR-260 Freezer door pocket Do not put ice cream or frozen food in freezer door pocket to Freezer room store for a long team. Opening and shutting the door can rise Do not put in any bottle such as up the temperature.
  • Page 6: Methods Of Exchanging Main Parts

    5. METHODS OF EXCHANGING MAIN PARTS 1) Remove knob by pulling 2) Remove the F-louver by pulling forward with inserting screw driver into the hole of F-louver. 3) Disconnect control box as 3. Louver insulator 1) Remove the louver insulator by pulling forward with case by hand so as not to break it.
  • Page 7 Methods of exchanging main parts 4. Bi-metal 1) Cut off the cable tie. 2) Take out the bimetal. Cable tie Bi-metal 5. Temperature fuse 1) Remove the temperature fuse out of evaporator pipe by screw driver. Tamp Fuse Black / Gray Tamp Fuse Fastrner...
  • Page 8 Methods of exchanging main parts 6. Defrost heater 1) Unscrew the one screws securing the evapoator. Evaporator fastening screw 2) Pull the accumulator slightly to the arrow direction. 3) Move evaporator forward as the figure and make working space to remove glass heater whith situates under the bottom of evaporator.
  • Page 9 Methods of exchanging main parts 5) Strip the aluminum tape fixing the defrost heater and cut both of lead wire. 6) Remove two (white and gray) defrost heater terminals among the lead wires mounted on left wall. 7) Detach the upper and lower part of heater cover from defrost heater by knife.
  • Page 10 Methods of exchanging main parts 7. Evaporator 1) Remove evaporator after removing temperature fuse and bimetal. 2) Remove two welded points 3) Remove one evaporator fixing screws 4) Extract evaporator forward with minimizing the pipe deformation after grasping the both sides of evaporator and pulling accumulator slightly forward.
  • Page 11 Methods of exchanging main parts 8. Fan motor 1) Dismantle fan motor by removing two screws. 9. Door switch 1) Remove the door switch out of cabinet by inserting "-" screwdriver to the inside of rubber packing. (Take care no to damage the rubber packing.) 10.
  • Page 12 Methods of exchanging main parts 11. R-Damper 1) After pressing both bottom surfaces of shade and pulling forward 2) To exchange the interior lamp,unscrew the lamp counterclockwise 3) Unscrew 2 screws 4) Pull forward lightly to detach 5) Detach the housing...
  • Page 13 Methods of exchanging main parts 6) Cut the 2 sealing material attached on the top 7) Separate insulated object A and B by detaching or cutting the OPP tape 8) Take off the cotton tape covered the R-damper sensor 9) Remove gear by inserting "-" screw driver...
  • Page 14 Methods of exchanging main parts 10) Spread out the R-damper sensor 11) Take out the damper by separating the damper insulated object A and B Assembly Caution Points Seal body 1. Replace the tape or seal to the original positions. 2.
  • Page 15: Trouble Shooting Procedure

    6. TROUBLE SHOOTING PROCEDURE 1) NO COOLING Symptoms Check point Cause Repairs Lamp off COMP off Power receptacle Power tailure Power plug Connection is not good Connect correctly Cooling cycle Insufficient Replace freezing mixture COMP on Refrigerant(leak) cycle and/or cabinet COMP.
  • Page 16 TROUBLE SHOOTING PROCEDURE ■ Decision for oil-clogging * First, replace dryer, in oil-discoloration replace the compressor * If the operation of the compressor is not good, replace the evaporator ■ Measuring procedure of coil resistance of comp * Measuring location of the coil resistance Terminal box Common Common...
  • Page 17 TROUBLE SHOOTING PROCEDURE 2) Solutions for other malfuntions Symptoms Check point Cause Repairs Temperature control The control button Set temperature which is suitable button and dial setting is not proper for the environment temperature Consumer's Closing an opening Opening and closing of misuse of door door is too frequent,...
  • Page 18 TROUBLE SHOOTING PROCEDURE Symptoms Check point Cause Repairs The foods in The wet food is placed in Wet foods shoud be placed far the refrigerator front of the outlet of the duct away form the outlet have frozen Operation Control button Control button is set at Set again to proper position Over...
  • Page 19: Cycle Refare Flow Chart

    7. CYCLE REFARE FLOW CHART Service Call Cycle problem? Usual repair Bad vacuum degree. Gas leak(High/low Bad compressor Cycle clogging Lack of refrigerant,etc. pressure sides) (Bad stroke,ejecting) . Drain compressor oil and compare with the standad. . When cutting the dryer, is gelled Judge by oil color of compressor oil attached near? And check if there is now...
  • Page 20: How To Judge Cooling Cycle Problem

    8. HOW TO JUDGE COOLING CYCLE PROBLEM Cooling problem service call Dial position "cold" power OK Is compressor rotating? Is F-FAN rotating? Is F-FAN rotating? Is F-FAN rotating? F-FAN problem. Electrical parts problem (Only applicable to the model with F-FAN Bad compressor Electrical part...
  • Page 21: Refrigrant Cycle Diagram

    9. Refrigrant cycle diagram...
  • Page 22: Machine Room View And Part List

    10. Machine room view and part list PART NAME PART NAME COMPRESSOR CASE VAPORI BASE COMP AS BAND RELAY FIX COMP WASH RELAY COVER ABSORBER COMP PIPE CONN SUC PIPE CONN HOT D TIMER AS or POWER BOX AS CORD POWER AS DRYER AS(R-12 or R-134a) TAPE COTTON CAP HOSE DRAIN...
  • Page 23: Welding

    11. Welding Welding 3% Welding BAG - 2 (35) 1.2D SOLDER SILVER SOLDER PAG BCUP - 3 OXYGEN OXYGEN ACETYLEN ACETYLEN NITROGEN NITROGEN COMWELD FLUX VAPOR Welding and Leak Test Welding MARK REMARK 6 POINT PINCH OFF 2 POINT 3 POINT...
  • Page 24: Parts List And Exploded Views

    In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer FR-260 to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr)
  • Page 25 Exploded views and parts list FR-260 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 3012918600 HINGE *M AS FR-260 3016004000 SPECIAL SCREW M6X16 SWCH22A 3010092010 ASSY URT *T DOOR 3012312550 GASKET F DR PVC+MAGNET 3019017700 POCKET F *T GPPS 3019017800 POCKET F *U...
  • Page 26 Partlist and Exploded views 2) Exploded views...
