Service Manual
Refrigerator
Model: FR-251
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : FR25100010
Advertisement
Table of Contents
Related Manuals for Daewoo FR-251
Summary of Contents for Daewoo FR-251
- Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.
-
Page 2: Table Of Contents
CONTENTS 1. Specification -----------------------------------------------------------------------------------------------1 2. External view ----------------------------------------------------------------------------------------------2 3. Wire diagram ---------------------------------------------------------------------------------------------3 4. Name of parts---------------------------------------------------------------------------------------------4 5. Air flow diagram-----------------------------------------------------------------------------------------5 6. Refrigerant cycle diagram ----------------------------------------------------------------------------6 7. Machine room view and part list-------------------------------------------------------------------7 8. Main components ---------------------------------------------------------------------------------------8 9. Door color specification -------------------------------------------------------------------------------11 10. -
Page 3: Specification
1. SPECIFICATION MODEL NAME FR-251 115g Refirgerant R134a 100g Cooling System Fan Cooling Convection Type Refrigeration System Air Forced Convection Defrost System Forced Fin-enaporator Type Defrost Operation Automatic Start & Stop Cold Control Adjustable Dial Freezer Refrigerator Capacity Total Height... -
Page 4: External View
2. EXTERNAL VIEW... -
Page 5: Wire Diagram
3. WIRE DIAGRAM L/BL : GREEN : BROWN : WHITE : PINK COMPRESSOR : BLACK TEMP : YELLOW FUSE : BLUE : GRAY WH/BL : WHITE WITH DEFROST BLUE STRIPE L/BL : LIGITH-BLUE BI-METAL LAMP GN/YW P-RELAY POWER CORD WH/BL MOTOR FREEZER GRAY... -
Page 6: Name Of Parts
4. NAME OF PARTS 1 Freezer Shelf 2 Freezer Temperature Controller 3 Ice Tray 4 Ice Box 5 Chilled Tray (*Option) 6 Refrigerator Temperature Controller 7 Lamp 8 Refrigerator Shelf 9 Vegetable Cover (Glass) 10 Vegetable Box 11 Adjustable Foot 12 Freezer Pocket (Bar Pocket Type) 13 Egg Pocket (*Option) -
Page 7: Air Flow Diagram
5. AIR FLOW DIAGRAM Freezer door pocket Do not put ice cream or frozen Freezer room food in freezer door pocket to Do not put in any bottle such as store for a long term. Opening beer or beverage because it can and shutting the door can rise up -16~-18 -16~-18... -
Page 8: Refrigerant Cycle Diagram
6. REFRIGERANT CYCLE DIAGRAM ACCUM SUC-PIPE... -
Page 9: Machine Room View And Part List
7. MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME PART NAME BASE COMP REINFORCE *L SIDE-PLATE PIPE FIXTURE BOLT COMP POWER BOX AS HOT-PIPE WASHER SWITCH P-RELAY AS CAPILLARY TUBE DRYER POWER CORD DRAIN HOSE ABSORBER CABINET URT AS SPECIAL SCREW COMPRESSOR SUC-PIPE... -
Page 10: Main Components
8. MAIN COMPONENTS 1. COMPRESSOR Refrigerant Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Comp. model EL19J-3 FL19J-2 SL21YE-5 PL19J-4 SL21YE-5 Part code 3953119330 3951119320 3954121A50 3956119340 3954121A50 Strating type RSCR RSIR RSIR RSCR RSIR Refrigerant R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz... - Page 11 5. DEFROST HEATER Refrigerant R12, R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Spec. 127V/110W 127V/110W 220V/110W Part code 401KG73730 401KG73730 3012803000 6. LAMP ASSEMBLY Refrigerant R12, R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Spec.
- Page 12 POWER CORD SPECIFICATION SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK 3011315000 CP-2PIN FOR EUROPEAN COUNTRY 401RA17200 CP-2PIN FOR OTHER COUNTRY 4006D17101 KP-30 FOR AMERICA 401PD17101 KP-211 FOR JAPAN & TAIWAN 3011300801 BP-3PIN 3011303010 #267 FOR CHILE 3011315310 FOR ISRAEL FOR U.K, MIDDLE ASIA 3011303050 BS-1363A...
-
Page 13: Door Color Specification
9. DOOR COLOR SPECIFICATION 1. ASSEMBLY URETHAN FREEZER DOOR 1) Key type Refrigerant R134a Dull lamina High glossy High glossy Dull lamina High glossy High glossy Color type Normal PCM Normal PCM sheet lamina sheet bright PCM sheet lamina sheet bright PCM Part code PFDT1UE120... - Page 14 COLOR TABLE 1. PCM type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) '97 BEIGE (BE215)
- Page 15 2. Lamina sheet type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) S/GOLD G/GREEN...
-
Page 16: Exploded View And Parts List
10. EXPLODED VIEW AND PARTS LIST 1. Exploded view... - Page 17 2. Parts list Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr) PART CODE PART NAME...
- Page 18 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 4019H14300 THEMO F DECO B-358 4019H27120 CONTROL BOX 4019H27111 COVER F C/B ASSY URT *U DOOR REFER TO # 11 4019H47022 GASKET R DR AS PVC-S RUBBER MAGNET 4010X37801 LINR R DR ABS 1.5 X 575 X1010 4018C37092 POCKET EGG PVC-H...
