PRELIMINARY INFORMATION
Calibration Interval
To ensure instrument
calibration of the 7B92A every 1000 hours of operation,
or every six months if used infrequently.
complete calibration, thoroughly clean and inspect this
instrument as outlined in the Maintenance section.
Tektronix Field Service
Tektronix, Inc.
repair and recalibration at local Field Service Centers
and the Factory Service Center.
Tektronix Field Office or representative for further
information.
Using This Procedure
Outline. To aid in locating a step in the
Performance Check or Calibration procedure, outlines
are given preceding Part I-Performance Check and Part
II Calibration procedure.
Performance Check.
instrument can be checked without removing the covers
or making internal adjustments by performing Part
Performance Check.
every facet of the instrument's calibration; but is
concerned primarily with those portions of the instrument
essential to measurement
operation.
Calibration Procedure.
Calibration procedure ensures that this instrument meets
the electrical specifications given in the Operators
manual. Where possible, instrument performance is
checked before an adjustment is made. For best overall
instrument performance when performing a complete
calibration procedure, make each adjustment to the
exact setting, even if the Check is within the allowable
tolerance.
Partial Calibration. A partial calibration is often
desirable after replacing components, or to touch up the
adjustment of a portion of the instrument between major
recalibrations.
REV A, JUN 1978
PERFORMANCE CHECK/CALIBRATION
accuracy, check
provides complete instrument
Contact your local
The performance of this
This procedure does not check
accuracy and
Completion of Part II
The
Triggering Calibration and Sweep Calibration.
perform a partial calibration, start at the beginning of the
the
desired section. To prevent unnecessary recalibration of
other parts of the instrument, readjust only if the
Before
tolerance given in the Check part of the step is not met.
The following test equipment and accessories, or
their equivalents, are required for complete calibration of
the 7B92A. Specifications given for the test equipment
are the minimum necessary for accurate calibration.
Therefore, some of the specifications listed here may
differ from the actual performance capabilities of the test
equipment.
correctly calibrated and operating within the listed
specifications. Detailed operating instructions for the test
equipment are not given in this procedure. Refer to the
test equipment instruction manual if more information is
needed.
If only a Performance Check procedure is
performed, not all of the listed test equipment will be
required. Items used only for the Calibration procedure
are indicated by footnote 1. The remaining pieces of
equipment are items common to both the Performance
Check and the Calibration procedure.
correct
Special Calibration Fixtures
Special Tektronix calibration fixtures are used only
where they facilitate instrument calibration.
special calibration fixtures are available from Tektronix,
Inc. Order by part number through your local Tektronix
Field Office or representative.
Calibration Equipment Alternatives
The Calibration procedure is based on the first
item of equipment given as an example of applicable
equipment.
control settings or calibration setup may need to be
altered slightly to meet the requirements of the substitute
equipment. If the exact item of test equipment is not
available, first check the Minimum Specifications column
in Table 5-1 carefully to see if any other equipment is
available that might suffice.
5-1
Calibration procedure

TEST EQUIPMENT REQUIRED

All test equipment is assumed to be
When other equipment is substituted,
Section 5-7B92A
is divided into
To
These
