Specification-7B92A
Characteristic
Differential Delay Time Measurement
Accuracy
+15°C to +35°C
.2 s/Div to .1 µs/Div
Both DELAY TIME MULT
dial settings at 0.50 or
greater
One or both DELAY TIME
MULT dial settings less than
0.50
50 ns/Div to 10 ns/Div
Both delay times equal to or
greater than 25 ns
One or both delay times less
than 25 ns
Delay Time Jitter
0.2 s/Div to 50 µs/Div
20 µs/Div to 10 ns/Div
1
Will not trigger on the sine waves of 8 div amplitude or less (internal), or 3 V or less (external) at
60 Hz or below.
2
For Internal Triggering only, the specified -3 dB frequency of the Vertical System replaces any
frequencies in the above table when the number in the table is greater than the -3 dB frequency of
the Vertical System.
3
Triggering signal amplitude requirements increased by factor of 10 for EXT - 10 operation.
4
The specified -3 dB frequency of the Vertical System replaces any frequencies in the above table
when the number in the table is greater than the -3 dB frequency of the Vertical System.
Table 2-2.
ENVIRONMENTAL
Refer to the Specification for the associated oscilloscope.
Table 2-1 (cont)
Performance Requirement
Within 0.75% of measurement +0.25% of full
scale
Within 0.75% of measurement +0.5% of full scale
+5 ns
Within 1.0% of measurement +0.5% of full scale
Within 1.0% of measurement +1.0% of full scale
+5 ns
1 part or less in 50,000 of the maximum available
delay time (10 times the TIME/DIV OR DLY
TIME switch setting)
1 part or less in 50,000 of the maximum available
delay time (10 times the TIME/DIV OR DLY
TIME switch setting +0.5 ns)
2-4
Table 2-3.
PHYSICAL
Net Weight 3.062 lbs (1.372 kg)
Dimensions See Fig. 2-1, Dimensional Drawing
Supplemental Information
Full scale is 10 times the
TIME/DIV OR DLY TIME
setting
Jitter specification does not
apply to the first 2% of the
maximum available delay
time (DELAY TIME MULT
dial setting less than 0.20)
REV A, JUN 1978
