Page 1: User Manual
KS105 Switch User Manual Shenzhen Kasda Digital Technology Co., LTD... -
Page 2: Table Of Contents
Content Chapter 1. Introduction of the Product ............................ 3 1.1 Overview of the Product ............................3 1.2 Features ................................. 3 Chapter 2. Installation ................................3 2.1 Mounting the Switch on a Desk ..........................3 2.2 Power On ................................4 Chapter 3. Identifying External Components .......................... 4 3.1 Front Panel ................................ -
Page 3: Overview Of The Product
The KS105 is poised to drive FE into the unmanaged and Smart switch, WLAN router, and CPE/Gateway markets with its comprehensive Layer 2 feature set, support for both DSL/cable modem and WLAN connectivity, and an industry-leading 5 FE of switching capacity—all on a single chip. -
Page 4: Front Panel
Chapter 3. Identifying External Components This Chapter describes the front panel, rear panel and LED indicators of the Switch. 3.1 Front Panel Figure 3-1 KS105 Switch Front Panel The Switch’s LEDs are located on the front panel. Power LED: This indicator will light up when the Switch powers on. -
Page 5: Rear Panel
The Power socket is where you will connect the power adapter. Please use the power adapter provided with this KS105 Switch. The KS105 Switch is equipped with 5 10/100Mbps Auto-Negotiation RJ45 ports LAN (1-5): where you will connect your network devices. -
Page 6: Chapter 4. Package Contents
Chapter 4. Package Contents The following items should be found in your box: One KS105 Switch One Power Adapter One CD Note: Make sure that the box contains the above items. If any of the listed items are damaged or missing, please contact with your distributor. -
Page 7: Appendix B: Troubleshooting
Appendix B: Troubleshooting 1. The Power LED is not lit Check to see if the power cord is connected to the Switch properly, and make sure the power source is 2. The LAN LED is not lit when a device is connected to the corresponding port Check to see if the cable connectors are firmly plugged into the Switch and the device, and verify the connected device is turned on and working well.
