Router - Lencore Spectra i.Net Installation And Operation Manual

section 5 section 5

5.10 | router

At every 30th OP a router is typically needed, for example a router
is used between the 30th and 31st OP to insure consistent data
transmissions.
Connecting from the OUT data port of the 30th OP, connect
the data cable to the router.
Exit the router by the data out and connect to the next OP (31st)
via the OP's data in using an integrated RJ45 connector.
DATA IN
DATA IN SIDE
NEVER PLUG A SPECTRA
i.NET ROUTER INTO ANY
COMPUTER OR NETWORK
OR LIKE DEVICE OTHER THAN A
SPECTRA i.NET EQUIPMENT.
DAMAGE TO COMPUTER OR LIKE
EQUIPMENT COULD OCCUR.
DATA OUT
DATA OUT SIDE
26
