Lencore Spectra i.Net Installation And Operation Manual page 18

section 5
5.1 | step-by-step i.Net OP installation instructions
PREPARATION
Review boxes. Refer to packing list and check equipment in boxes. Be certain you have:
1
All Operating Platforms – Please secure all OPs to a very safe place.
a
i.LON (make sure you secure the i.LON – approximate cost $2000.00).
b
The terminator(s). Keep these in a safe place.
c
Power supplies, MPI (headend enclosure).
d
Speaker boxes. Count all the items to ensure that you have all of your equipment.
e
Open speaker boxes to properly count the number of speakers you have.
2
Review Wiring and Installation Drawings:
Verify where wiring will be installed BEFORE placing equipment.
a
Check wiring runs to properly estimate needed quantity of wire for the project.
b
Check quantity for: Power Wire (16/2), Data Wire (CAT 5e, 4 pair), Speaker Wire
(CAT 5e, 4 pair). Check that all wiring is Plenum Rated, Only use Plenum Rated
wiring in Plenums.
Verify where OPs and speakers will be installed. Please note OPs need
c
to be installed in sequence.
Review location for placing the head end equipment (electrical or IT closet) – make
3
sure that you have access to power in the closet. Follow all safety precautions. Use a
UPS (uninterruptible power supply) for powering the head end for all emergency
paging systems. Check for and identify intended placement for the:
Wall mounted enclosure or rack mounted drawer
a
4
Identify any major site impediments such as:
Slab-to-slab wall
a
Shafts
b
Risers (wiring raceways from floor to floor
c
d Obstructions in plenum
REMINDER
Secure all OPs, MPI AND
i.LON equipment on site.
Store securely & safely.
OPs, MPI AND i.LON are
expensive items!
14
