DW DWC-B6763WTIR Manual page 17

COLOR
WB MODE
ATW
Auto Tracking White Balance Control mode compensates for color temperature changes
between 2400K
AWB
Auto White Balance Control mode compensates for color temperature changes
lower than 2000K
PUSH
Push fixes the white balance based on the current lighting automatically.
MANUAL
Users can control the white balance manually by changing RED GAIN and BLUE
GAIN (see below).
C-TEMP: Select the color temperature for the white balance setup. If enabled,
the Red and Blue Gain settings will be set automatically according to the
C-TEMP selected.
RED GAIN: 0 ~ 20. Adjusts the amount of red in the image.
BLUE GAIN: 0 ~ 20. Adjust the amount of blue in the image.
COLOR GAIN
Set the color gain from 0~20.
o o
and 11000K .
o
and higher than 15000K
o
.
17
