CONTROL BOARD*

Joystick: Controls the OSD menu.
1
Remove the camera's lens cover by rotating it counter-clockwise.
2
Use the Joystick to control the camera's OSD options.
Secondary Connector:
Video Output Connector for
On-Site Configuration
11
