Baxi LUNA3COMFORT Installers And Users Instructions

High efficiency wall-mounted gas-fired boilers
Hide thumbs
Table of Contents

Advertisement

Quick Links

High efficiency wall-mounted gas-fired boilers
EN
Высокопроизводительный настенный газовый котел
RU
HU
Závěsný plynový kotel s vysokou účinností
CS
Caldera mural de gas de alto rendimiento
ES
Centrale murale pe gaz cu randament ridicat
RO
Επίτoιχoς λέβητας αερίoυ υψηλής απoδoσης
EL
Installer's and User's Instructions
Руководство по эксплуатации и монтажу
Magas hozamú fali gázkazán
Felhasználói és szerelői kézikönyv
Návod k použití určený pro uživatele a technika
Manual para el usuario y el instalador
Instrucţiuni pentru instalator i pentru utilizator
Oδηγίες χρήσης για τo χρήστη και τoν εγκαταστάτη

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUNA3COMFORT and is the answer not in the manual?

Questions and answers

Related Manuals for Baxi LUNA3COMFORT

Summary of Contents for Baxi LUNA3COMFORT

  • Page 1 High efficiency wall-mounted gas-fired boilers Installer’s and User’s Instructions Высокопроизводительный настенный газовый котел Руководство по эксплуатации и монтажу Magas hozamú fali gázkazán Felhasználói és szerelői kézikönyv Závěsný plynový kotel s vysokou účinností Návod k použití určený pro uživatele a technika Caldera mural de gas de alto rendimiento Manual para el usuario y el instalador Centrale murale pe gaz cu randament ridicat...

  • Page 2: Table Of Contents

    (ISO 9001), environmental (ISO 14001) and health and safety (OHSAS 18001) systems. This means that BAXI S.p.A. includes among its objectives the safeguard of the environment, the reliability and quality of its products, and the health and safety of its employees.

  • Page 3: Instructions Prior To Installation

    1. INSTRUCTIONS PRIOR TO INSTALLATION This boiler is designed to heat water at a lower than boiling temperature at atmospheric pressure. The boiler must be connected to a central heating system and to a domestic hot water supply system in compliance with its performances and output power.

  • Page 4: Commissioning Of The Boiler

    3. COMMISSIONING OF THE BOILER To correctly light the boiler proceed as follows: press the button, to set the gas boiler mode as described in section 3.2. Note: if summertime mode is setting, the boiler will light only during a D.H.W. demand. +/- respective buttons as described in section 3.3.
  • Page 5 SYMBOL MEANING There are 4 power levels displayed during boiler operation, relevant to the gas boiler modulation, as shown in fig. 2: Figure 2 3.2 DESCRIPTION OF BUTTON (Summer - Winter - Heating only - Off) Press this button to set the following boiler operation modes: In SUMMER mode the symbol is shown on the display.
  • Page 6 3.4 ROOM AND DOMESTIC HOT WATER (D.H.W.) TEMPERATURE ADJUSTMENT The room ( ) and D.H.W. ( ) temperature adjustment are carried out by pressing the relative +/- buttons (figure 1). When the burner is lighted the display shows the symbol ( ) as described in section 3.1. During a CH mode, the display shows a CH ( ) symbol and the room temperature value (°C).
  • Page 7 On 1 Of 1 On 2 Of 2 On 3 Of 3 On 4 Of 4 (monday) (tuesday) (wednesday) (thursday) 06:00 08:00 11:00 13:00 17:00 23:00 24:00 24:00 (friday) (saturday) (sunday) To set a single time band, proceed as follows: 1) Press the IP button and then the button 2) choose a day of the week (1…7) by repeatedly pressing the buttons +/-...
  • Page 8 Summary table of available groups of days Group “MO-FR” from Monday to Friday As per table in paragraph 3.6.1. Group “SA-SU” Saturday and Sunday 07:00 – 23:00 Group “MO-SA” from Monday to Saturday As per table in paragraph 3.6.1. Group “MO-SU” every day of the week As per table in paragraph 3.6.1.

  • Page 9: Special Functions

    4. SPECIAL FUNCTIONS 4.1 ECONOMY - COMFORT FUNCTION This function enables the user to set two different room temperature setpoints: Economy / Comfort. For more simplicity it’s better to set the COMFORT value temperature higher than the ECONOMY value temperature. To set the required room temperature, press the button: ECONM”...
  • Page 10 4.3 TEMPERATURE VALUES MODIFICATION BY PRESSING THE BUTTON To modify the room temperature values, proceed as follows: IP button to enable the PROGR function; button to select the required function as described in the following table: Function Display Description of function The set temperature value Boiler operation in heating mode at nominal temperature.

  • Page 11: Filling The Boiler

    WARNING: do not press any button after having enabled this function. By pressing some of the remote control buttons, it is possible that the manual function is enabled by mistake (in this case the display shows the symbol) and that causes the “Holiday Program”...

  • Page 12: Prolonged Standstill Of The System. Frost Protection

    8. PROLONGED STANDSTILL OF THE SYSTEM. FROST PROTECTION We recommend you avoid draining the whole system as water replacements engender purposeless and harmful limestone deposits inside the boiler and on the heating elements. In case the boiler is not operated during wintertime and is therefore exposed to danger of frost we suggest you add some specific-purpose anti-freeze to the water contained in the system (e.g.: propylene glycole coupled with corrosion and scaling inhibitors).

  • Page 13: Servicing Instructions

    ERROR CODE CORRECTIVE ACTION Press the OK button (figure 1) for at least 2 seconds. If this fault Gas supply fault persist, call an authorised Service centre. Press the OK button (figure 1) for at least 2 seconds. If this fault Safety thermostat sensor tripped persist, call an authorised Service centre.

  • Page 14: General Information

    11. GENERAL INFORMATION The following remarks and instructions are addressed to Service Engineers to help them carry out a faultless installation. In- structions regarding lighting and operation of the boiler are contained in the ‘Instructions pertaining to the user’ section. Note that installation, maintenance and operation of the domestic gas appliances must be performed exclusively by quali- fied personnel in compliance with current standards.

  • Page 15: Boiler Installation

    13. BOILER INSTALLATION Decide upon the boiler location, then tape the template on the wall. Connect the pipework to the gas and water inlets prearranged on the template lower bar. We suggest you fit two G3/4 stop cocks (available on demand) on the central heating system flow and return pipework;...

  • Page 16: Installation Of Flue And Air Ducts

    15. INSTALLATION OF FLUE AND AIR DUCTS Models 240 Fi - 310 Fi - 1.240 Fi - 1.310 Fi We guarantee ease and flexibility of instal lation for a gas- fired forced draught boiler thanks to the fittings and fixtures supplied (described below).
  • Page 17 15.1 HORIZONTAL FLUE TERMINAL INSTALLATION OPTIONS L max = 5 m 240 Fi - 1.240 Fi Ø 60/100 mm - 9 m Ø 80/125 mm L max = 4 m 310 Fi - 1.310 Fi Ø 60/100 mm - 8 m Ø 80/125 mm L max = 4 m 240 Fi - 1.240 Fi Ø...
  • Page 18 This type of ducting allows to disengage exhaust flue gases both outside the building and into single flue ducts. Comburant air may be drawn in at a different site from where the flue terminal is located. The splitting kit consists of a flue duct adaptor (100/80) and of an air duct adaptor. For the air duct adaptor fit the screws and seals previously removed from the cap.
  • Page 19 15.4 SPLIT FLUE OVERALL DIMENSIONS 15.5 SEPARATED HORIZONTAL FLUE TERMINALS INSTALLATION OPTIONS IMPORTANT: Ensure a minimum downward slope of 1 cm toward the outside per each metre of duct length. In the event of installation of the condensate collection kit, the angle of the drain duct must be directed towards the boiler.

  • Page 20: Connecting The Mains Supply

    15.6 SEPARATED VERTICAL FLUE TERMINALS INSTALLATION OPTIONS L max = 15 m 240 Fi - 1.240 Fi L max = 14 m 240 Fi - 1.240 Fi L max = 12 m 310 Fi - 1.310 Fi L max = 10 m 310 Fi - 1.310 Fi Important: if fitting a single exhaust flue duct, ensure it is adequately insulated (e.g.: with glass wool) wherever the duct passes through building walls.

  • Page 21: Remote Control Installation

    17. REMOTE CONTROL INSTALLATION The remote control can be installed directly on the boiler or in the wall. 17.1 INSTALLING THE REMOTE CONTROL ON THE BOILER FRONT PANEL To fit the remote control inside the boiler front control panel, proceed as follows: 1.

  • Page 22: Gas Change Modalities

    DESCRIPTION OF BUTTON button does not operate as described in section 4.1 (ECONOMY-COMFORT function). The gas boiler operates when both the programmed time slot and the room thermostat required heating. By pressing the button during a room thermostat heating request, it is possible “to forced” a Heating request even if the programmed time slot does not required Heating.
  • Page 23 C) Pressure adjusting device setting (Figure 13) test point (Pb); connect, for sealed chamber models only, the negative pressure test point of the manometer to a “T” fitting in order to join the boiler adjusting outlet, the gas valve adjusting outlet (Pc) and the manometer. (The same me- asurement can be carried out by connecting the manometer to the pressure test point (Pb) after removing the sealed chamber front panel);...

  • Page 24: Parameters Display

    Table of burner pressures 240 Fi - 1.240 Fi 240 i - 1.240 i 310 Fi - 1.310 Fi Gas used injector diameter (mm) 1,18 0,74 1,18 0,74 1,28 0,77 Burner pressure (mbar*) REDUCED HEAT OUTPUT Burner pressure (mbar*) 11,3 29,4 10,0 26,0...

  • Page 25: Additional Information

    ADVANCED INFORMATION “PWR %” Power level/modulating flame (%). “P BAR” Water pressure heating circuit (bar). Water flow rate (l/min). PARAMETERS SETTING “K REG” Central Heating setting constant (0,5...9,0 - factory setting 3 - Refer to section 25 - Graph 3). Press +/- buttons to set the value.

  • Page 26: Parameters Setting

    20. PARAMETERS SETTING To access the Parameters setting mode proceed as follows: IP button; button then press together the button. When the function is activated, the display shows “F01” with the value of the selected parameter. Parameters setting buttons for scrolling parameters; buttons to change the single parameter value;...

  • Page 27: Control And Operation Devices

    21. CONTROL AND OPERATION DEVICES The boiler has been designed in full compliance with European reference standards and in particular is equipped with the following: 310 Fi - 1-240 Fi - 1.310 Fi) This switch allows the burner to switch on provided the exhaust flue duct efficiency is perfect. In the event of one of the following faults: The boiler will stay on stand-by and the display shows error code 03E (see section 9).

  • Page 28: Positioning Of The Ignition And Flame Sensing Electrode

    22. POSITIONING OF THE IGNITION AND FLAME SENSING ELECTRODE Figure 15 23. CHECK OF COMBUSTION PARAMETERS The boiler has two connection points specifically designed to allow technicians to measure the combustion efficiency after installation and ensure that the combustion products do not constitute a health risk. One connection point is connected to the flue gas discharge circuit, and allows monitoring of the quality of the combustion products and the combustion efficiency.

  • Page 29: Connection Of The External Probe

    25. CONNECTION OF THE EXTERNAL PROBE The boiler is prearranged for connection of an external probe (supplied as accessory). For the connection, refer to the figure below (terminals 3-4) and the instructions supplied with the probe. Figure 16 With the external temperature sensor connected, the heating delivery temperature can be adjusted in two different ways.

  • Page 30: Connecting An External Hot Water Tank And 3-Way Valve Motor

    K REG constant curves T.m (°C) Tm MAX = 45°C T.e (°C) T.m (°C) Tm MAX = 85°C Graph 3 T.e (°C) TM = flow temperature (°C) = external temperature (°C) 26. CONNECTING AN EXTERNAL HOT WATER TANK AND 3-WAY VALVE MOTOR Models 1.240 i - 1.240 Fi - 1.310 Fi The DHW priority NTC sensor and the 3-way valve motor are not included, but are supplied as accessories.
  • Page 31 hot water tank unit heating unit 3-way valve motor (accessory) connection terminal block DHW priority hot water tank sensor heating delivery hot water tank delivery heating/hot water tank return MOTOR (ACCESSORY) Figura 17 NOTES Make sure parameter F03 = 05 (section 20). Models 1.240 i .

  • Page 32: Electrical Connections To A Multi-Zone System

    27. ELECTRICAL CONNECTIONS TO A MULTI-ZONE SYSTEM 27.1 - RELAY CARD (SUPPLIED AS AN ACCESSORY) CONNECTION) The relay card is not included but is supplied as an accessory. Connect terminals 1-2-3 (common-normally closed - normally open) of connector CN1 to terminals 10-9-8 of the boiler terminal block M2 (figure 18).

  • Page 33: How To Purge The Dhw System From Limestone Deposits

    28. HOW TO PURGE THE DHW SYSTEM FROM LIMESTONE DEPOSITS (Not fitted on 1.240 i - 1.240 Fi and 1.310 Fi models) To clean the DHW system it is not necessary to remove the DHW heat exchanger if the assembly is equipped with the appropriate taps (supplied on demand) placed on the hot water outlet and inlet.

  • Page 34: Boiler Schematic

    32. BOILER SCHEMATIC 240 Fi - 310 Fi 310 Fi heating domestic domestic heating inlet water outlet water inlet return Figure 20 Key: 14 Fan 15 Positive pressure point 1 D.H.W. priority sensor (for 310 Fi model the positive point must be closed) 2 Water pressure switch 16 Air pressure switch 3 Three way valve...
  • Page 35 240 i heating domestic domestic heating inlet water outlet water inlet return Figure 21 Key: 13 Flue hood 1 D.H.W. priority sensor 14 Flue thermostat 2 Water pressure switch 15 Flame detector electrode 3 Three way valve 16 Burner 4 D.H.W. NTC sensor 17 Burner injectors 5 Flow sensor with filter and water flow rate limiter 18 D.H.W.
  • Page 36 1.240 Fi - 1.310 Fi 1.310 Fi 0606_2701 heating domestic domestic heating inlet water outlet water inlet return Figure 20 Key: 1 Automatic by-pass 12 Positive pressure point 2 Water pressure switch (for 1.310 Fi model the positive point must be closed) 3 Three way valve 13 Air pressure switch 4 Gas valve...
  • Page 37 1.240 i heating domestic domestic heating inlet water outlet water inlet return Figure 21 Key: 1 Automatic by-pass 10 Flue hood 2 Water pressure switch 11 Flue thermostat 3 Three way valve 12 Flame detector electrode 4 Gas valve 13 Burner 5 Expansion vessel 14 Burner injectors 6 Ignition electrode...

  • Page 38: Illustrated Wiring Diagram

    33. ILLUSTRATED WIRING DIAGRAM 240 Fi - 310 Fi 925.220.4 - EN...
  • Page 39 240 i 925.220.4 - EN...
  • Page 40 1.240 Fi - 1.310 Fi 925.220.4 - EN...
  • Page 41 1.240 i 925.220.4 - EN...

  • Page 42: Technical Data

    (**) according to EN 60529 As BAXI S.p.A. constantly strives to improve its products, it reserves the right to modify the information contained in this document at any time and without prior notice. This document is issued purely for the sake information and should not be considered as a contract with third parties..
