ENGLISH Index BEFORE USING THE APPLIANCE ..............2 General warnings ......................2 Old and out-of-order fridges ................... 4 Safety warnings ....................... 4 Installing and operating your fridge ................5 Before Using your Fridge ....................5 THE VARIOUS FUNCTION AND POSSIBILITIES ..........6 Information about NO FROST technology ..............
PART- 1. BEFORE USING THE APPLIANCE General warnings WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
Page 5
ENGLISH - bed and breakfast type environments; - catering and similar non-retail applications • If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
Old and out-of-order fridges • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC.
ENGLISH • Do not re-freeze frozen goods after they have melted. This may cause health issues like food poisoning. • Do not cover the body or top of fridge with lace. This affects the performance of your fridge. • Fix the accessories in the fridge during transportation to prevent damage to accessories.
PART- 2. THE VARIOUS FUNCTION AND POSSIBILITIES Information about NO FROST technology No-Frost fridges differ from other static fridges in their operating principle. In normal fridges, the humidity entering the fridge in the door openings and the humidity of the food causes freezing in the freezer compartment.
ENGLISH Refrigerator Thermostat Setting; 1 – 2 : For less coldly conditions. 3 – 4 : For normal conditions. 5 – MAX : For colder conditions. Warnings about Temperature Adjustments • It is not recommended that you operate your fridge in environments colder than 10°C in terms of its efficiency.
Fast Freezing Shelf • Use the fast freezing shelf to freeze home cooking (and fresh foods which is wanted to freeze) more quickly because of the freezing room’s greater freezing power. • For opening the shelf pull the cover up, and slide it in to the shelf.
ENGLISH Fresh dial Fresh dial In case of the crisper is totally full, the fresh dial is located in front of crisper, should be opened. By means of this the air in the crisper and humidity rate will be controlled and endurance life will be increased.
PART- 3. ARRANGING FOOD IN THE APPLIANCE Refrigerator Compartment • To set the refrigerator compartment to 2-3 graphic bar will be enough for normal conditions. • To reduce humidity and consequent increase of frost never place liquids in unsealed containers in the refrigerator.
ENGLISH • Frozen foods should be transported in appopriate containers to maintain the quality of the food and should be returned to the freezing surfaces of the unit in the shortest possible time. • If a package of frozen food shows the sign of humidity and abnormal swelling it is probable that it has been previously stored at an unsuitable temperature and that the contents have deteriorated.
Replacing The Refrigerator and Freezer Light Bulb 1. Unplug the unit from the power supply, 2. Remove the refrigerator light cover with a minus screw driver, and take out the cover.(A) 3. Change the present light bulb with a new one of not more than 15 W.(B) 4.
ENGLISH TRANSPORTATION AND CHANGING OF INSTALLA- PART- 5. TION POSITION Transportation and Changing of Installation Position • The original packages and foamed polystyrene (PS) can be concealed if required. • In transportation the appliance should be tied with a wide stripe or a strong rope. The rules written on the corrugated box must be applied while transporting.
Page 16
IIf your fridge is operating too loudly; Normal Noises Cracking (Ice cracking) Noise: • During automatic defrosting. • When the appliance is cooled or warmed (due to expansion of appliance material). • Heard when the thermostat switches the compressor on/off.
ENGLISH Tips for saving energy 1– Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near heat source (radiator, cooker.. etc. ). Otherwise use an insulating plate. 2– Allow warm food and drinks to cool down outside the appliance. 3–...
THE PARTS OF THE APPLIANCE AND THE PART- 7. COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. 1) Fast freezing shelf 10) Refrigerator lamp box / cover...
Page 19
ENGLISH ELECTRICAL CONNECTION (FOR UK TYPE PLUG) For your safety please read the following information Warning: This appliance must be earthed. This appliance operates from 220-240 volts and should be protected by a 13 amp fuse in the plug. The appliance is supplied with a standard 13 amp 3-pin mains plug fitted with a 13-amp fuse. Should the fuse require replacement, it must be replaced with a fuse rated at 13 amp and approved to BS1362.
