Built-In All Freezer
E32AF75JPS professional series
Custom-Fit
More space inside gives you plenty of space to
stock up so you'll always have food on hand for
any occasion.
Custom-Design
The ultimate organization system features
adjustable glass shelves, Smooth-Glide
full-width baskets and versatile door storage.
Smooth-Glide
Full-width drawers glide out smoothly and fully
extend giving you easy access to what's inside.
PureAdvantage
Keeps clean, filtered air circulated throughout
to prevent odor transfer.
1
Kits are designed to fit either 79" or 75" opening height. For 79" cutout opening
height, installation requires use of top louvered grille; for 75" cutout opening height,
installation requires use of top trim piece and shortening of both side trim pieces.
Sub-Zero
®
is a registered trademark of Sub-Zero, Inc.
Built-In Side-by-Side
Configuration
Shown with companion, All-Refrigerator
model E32AR75JPS and optional
stainless steel 84" Louvered Trim Kit.
(Double – PN # ECP8472SS)
Shown with optional stainless
steel 72" Collar Trim Kit.
(Single – PN # ECP7236SS)
Capacity
Organization System
®
®
Freezer Drawers
®
Air Filter
BUILT-IN ALL FREEZER
CAPACITIES
Volume
Shelf Area
EXTERIOR
Professional Door and Handle Design
Custom-Set
Controls
Hidden Door Hinge Covers
Air Filter Indicator
Electronic Control Lock
INTERIOR CONVENIENCES
PureAdvantage
®
Air Filter
Custom-Design
Glass Shelves
Smooth-Glide
®
Full-Width Bottom Basket
Smooth-Glide
®
Full-Width Mid-Level Baskets
Soft Freeze
Bin
Extreme Freeze
Adjustable Door Bins
Condiment Shelf
Theatre LED Lighting
Custom-Set
Digital Temperature Control System
Temp Alarm System / Door-Ajar Alarm / Power Failure Alarm
Ice Maker
Door Closer
Luxury-Quiet
Design
ADDITIONAL FEATURES
ENERGY STAR
®
Sabbath Mode (Star-K
®
Certified)
ACCESSORIES
84" Louvered Trim Kits: Single – PN # ECP8436SS
Double – PN # ECP8472SS
72" Collar Trim Kits:
Single – PN # ECP7236SS
Double – PN # ECP7272SS
1
79" Louvered / 75" Collar Trim Kits
:
Single – PN # TRIMKITSS1
Double – PN # TRIMKITSS2
PureAdvantage
®
Air Filter
Replacement Cartridge – PN # EAFCBF
SPECIFICATIONS
Product Dimensions –
Height (Cabinet)
(Including Door)
Width
Depth (Including Door)
(with 90° Door Open)
Power Supply Connection Location
Water Inlet Location
Voltage Rating
Connected Load (kW Rating) @ 115 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
An electrical supply with grounded three-prong receptacle is required. The power
supply circuit must be installed in accordance with current edition of National Electrical
Code (NFPA 70) and local codes & ordinances.
NOTE: Always consult local and national electric and plumbing codes. Refer to Product
Installation Guide for detailed installation instructions on the web at electroluxicon.com.
Specifications subject to change.
Optional Trim Kits
84" Louvered Trim Kits
(ECP8436SS & ECP8472SS)
Designed as a replacement option for the Sub-Zero
models and for new-build installation.
72" Collar Trim Kits
(ECP7236SS & ECP7272SS)
Designed as a replacement option for the Sub-Zero
models and for new-build installation.
79" Louvered / 75" Collar Trim Kits
Designed as a replacement option for Electrolux ICON
E32AR75FPS and E32AF75FPS and for new-build installation.
18.6 Cu. Ft.
19.7 Sq. Ft.
Yes
Yes
Yes
Yes
Yes
Yes
2
1
2
1
Yes
4
1
Yes
Yes
Yes
Factory-Installed
Yes
Yes
Yes
Yes
Optional
Optional
Optional
Optional
Optional
Optional
Optional
70-5/8"
71-3/8"
32"
26-1/2"
57-3/8"
Right Bottom Rear
Left Bottom Rear
120V /60 Hz /20A
0.55
20
247 Lbs.
®
brand 650 Series
®
brand 601 Series
1
(TRIMKITSS1 & TRIMKITSS2)
®
brand models
electroluxicon.com
