- Page 1 ST/PRO Owner’s manual Mode d’emploi Bedienungsanleitung Manual del propietario Manuale d’uso e manutenzione...
-
Page 2: Special Message Section
DO NOT modify this unit or commission others to do so unless specifically authorized by Yamaha. Prod- uct performance and/or safety standards may be dimin- ished. Claims filed under the expressed warranty may be denied if the unit is/has been modified. -
Page 3: Important Safety Instructions
(where applica- manufacturer. ble) are well secured BEFORE using. Benches sup- plied by Yamaha are designed for seating only. No Use only with the cart, stand, tripod, other uses are recommended. bracket, or table specified by the... - Page 4 If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Corporation of America, Electronic Service Division, 6600 Orangethorpe Ave, Buena Park, CA 90620 The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.
- Page 5 Information for Users on Collection and Disposal of Old Equipment This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in accordance with your national legislation and the Directives 2002/96/EC.
- Page 6 Información para Usuarios sobre Recolección y Disposición de Equipamiento Viejo Este símbolo en los productos, embalaje, y/o documentación que se acompañe significa que los productos electrónicos y eléctricos usados no deben ser mezclados con desechos hogareños corrientes. Para el tratamiento, recuperación y reciclado apropiado de los productos viejos, por favor llévelos a puntos de recolección aplicables, de acuerdo a su legislación nacional y las directivas 2002/96/EC.
- Page 7 ST/PRO Owner’s manual...
- Page 8 10-1 Nakazawa-cho, Naka-ku, Hamamatsu, Shizuoka, 430-8650, JAPAN Piano Development Department, Yamaha Corporation The source code will be provided at no charge; however, we may require you to reimburse Yamaha for the cost of delivering the source code to you. • Note that we shall bear no responsibility whatsoever for any damage arising from changes (additions/ deletions) made to the software for this product by a third party other than Yamaha (or party authorized by Yamaha).
- Page 9 Important Precautions Read the following before operating the Disklavier. ■ Warnings • Set the volume level on all the devices to minimum before applying power. • Do not locate the Disklavier in a place subject to • Do not play the Disklavier at a high volume for excessive heat, low temperatures, or direct extended periods;...
-
Page 10: Table Of Contents
Table of Contents Chapter 1 Introduction Features ..............1 Items Supplied with the Disklavier ......1 Names of Parts and Their Functions......2 Compatible Media and File Format ......7 Basic Disklavier Terminology .........8 Chapter 2 Getting Started Connecting the AC Power Cable ......9 Turning the Power On/Off ........10 Connecting the Disklavier and Smart Device to a Network ............12... -
Page 11: Introduction
• 500 well-known piano pieces are stored internally, ranging in genre from classical right through to popular music and jazz, there for you to enjoy as the mood takes you. Songs including vocals from Yamaha artists even allow you to experience the atmosphere of a live performance, and Yamaha also provides the 24- hour DisklavierRadio streaming service. -
Page 12: Names Of Parts And Their Functions
Chapter Introduction Names of Parts and Their Functions ■ Switch Box (Front and Bottom Panel) Front panel Bottom panel POWER button USB port Turns on or off the Disklavier. Used to connect the USB flash memory. Note: VOLUME +/– buttons The unit cannot detect the USB flash memory if two or more Adjust the volume. - Page 13 Chapter Introduction ■ Switch Box (Rear Panel) AUTO PLAY switch USB port Activates or deactivates the auto play function. You Used to connect the USB wireless LAN adaptor can make settings for the auto play function using (UD-WL01). the ENSPIRE Controller app. Note: The unit cannot detect the USB flash memory if two or more AUTO OFF MODE switch...
- Page 14 Chapter Introduction ■ Control Center Unit (for Grand Pianos) USB (To DEVICE) port DIGITAL OUT jack Used to connect the USB flash memory. Used to connect to the digital input jack of external audio device using a digital coaxial cable. Note: The unit cannot detect the USB flash memory if two or more OMNI (SYNC) IN/OUT jacks...
- Page 15 Chapter Introduction ■ Inlet Box (for Upright Pianos) Main switch LAN port Turns on or off the main power. Used to connect the router or hub using an Ethernet cable. OUTPUT jacks USB (To HOST) port Used to connect optional monitor speakers. Used to connect the computer using a USB cable.
- Page 16 Chapter Introduction ■ Monitor Speaker (for Grand Pianos)* HIGH LINE LOW/HIGH volume controls LINE 1/2 volume controls Adjust the bass/treble sound volume. Adjust the sound volume for each line input. Note: Power indicator For normal use, turn down the LINE 2 volume completely, and Lights up while the speaker is turned on.
-
Page 17: Compatible Media And File Format
USB port as it may become unusable. The Disklavier can handle these four types of file format: Note: Song File Format Extension Yamaha does not assure the operation of the commercially Format available USB flash memories. MIDI SMF0 .MID Standard MIDI File format 0 for playback and recording. -
Page 18: Basic Disklavier Terminology
Selections include compatibility between MIDI devices. When a song songs for listening enjoyment, piano study disks for in the Yamaha XG format is played on another XG the piano student, and accompaniments for vocal compatible tone generator or synthesizer, it will and instrumental practice. -
Page 19: Getting Started
Getting Started Chapter Connecting the AC Power Cable Warning: Connect the AC power cable extending from the piano to Use the AC power cable attached to the AC wall outlet. the piano. Use of other AC power cables may result in damage, overheating, or fire. -
Page 20: Turning The Power On/Off
Chapter Getting Started Turning the Power On/Off ■ Turning the Power On Make sure that the main switch on the power supply unit/ inlet box is turned on. (Grand piano) Power supply unit (located underneath the piano) MAINS (Upright piano) MAINS Inlet box (located on the rear) - Page 21 Chapter Getting Started ■ Turning the Power Off (Standby) Press the POWER button. The POWER indicator flashes (every 0.5 seconds). Flashing After several seconds, the POWER indicator lights up dimly. ■ Setting the Auto Power-off Function You can turn the power off automatically if you do not use the Disklavier for the time specified with the ENSPIRE Controller app.
-
Page 22: Connecting The Disklavier And Smart Device To A Network
Disklavier and smart device. Internet features is done at the risk Here is the summary for connection: of the purchaser. In no event shall Yamaha, its subsidiaries or Yamaha’s and/or its subsidiaries’ Choose the connection method (page 13). directors, officers, or employees be... -
Page 23: Choosing The Network Connection Method
Chapter Getting Started Choosing the Network Connection Method You can use one of the three methods of connections below. Select one which is most suitable for your network environment. ■ Wireless Network Connection by WPS ( page 15) Choose this if you have a wireless router (access point) that supports WPS. - Page 24 Chapter Getting Started ■ Wired Network Connection ( page 17) Choose this if you have a wireless router (access point) that does not Note: Use an STP (shielded twisted pair) support WPS. Connection will be established via wireless router (access cable for connection.
-
Page 25: Wireless Network Connection By Wps
Chapter Getting Started Wireless Network Connection by WPS If your wireless router (access point) supports WPS, you can easily Note: To check whether your wireless connect the Disklavier to a network just by following the procedures below, router (access point) supports WPS, without making any additional settings, such as entering a password. - Page 26 Chapter Getting Started Note: Press the WPS button on your wireless router (access For details on the WPS setting, refer point) within two minutes after step 5. to the owner’s manual supplied with your wireless router (access point). When the Disklavier is successfully connected to the wireless router (access point), the LED lamp on the USB wireless LAN adaptor (UD-WL01) lights up.
-
Page 27: Wired Network Connection
Chapter Getting Started Wired Network Connection If your wireless router (access point) does not support WPS, you can connect the Disklavier to a wireless router (access point) using an Ethernet cable. Press the POWER button to turn the power off. (For grand pianos) Connect the wireless router (access point) to the LAN port on the control center unit using an Ethernet cable. -
Page 28: Direct Wireless Connection
Chapter Getting Started Press the POWER button to turn the power on. Connection between the Disklavier and the wireless router (access point) is automatically established in approximately 15 to 20 seconds. Note: Open the Wi-Fi setting screen on your smart device. For details on the Wi-Fi setting, refer to the owner’s manual supplied with your smart device. -
Page 29: Using The Enspire Controller App
IDC service with any other Please register at the following website: instrument, you do not need to https://member.yamaha.com/myproduct/regist/ register again. You can use your ID and password obtained through Once you have an IDC account, you will interact with that account using that registration. -
Page 30: Other Settings
• You can also update your Disklavier using the ENSPIRE You can download the update program from the following site: Controller app. To update your http://download.yamaha.com/ Disklavier using the app, Internet connection is required. Note: Copy “en_update.bin” included in the downloaded file to It is recommended that the USB the root directory of the USB flash memory. -
Page 31: Initializing Network Settings
Chapter Other Settings Initializing Network Settings If the ENSPIRE Controller app cannot connect to your Disklavier due to the improper network settings, follow the procedure below to initialize network settings on your Disklavier. Press the POWER button to turn the power off. Holding the VOLUME +/–... -
Page 32: Chapter 4 Troubleshooting
Troubleshooting Chapter If you are having difficulty operating the Disklavier, see if any of the symptoms listed below apply to your problem and follow the recommended remedy. Power Symptom Remedy The Diskalvier does not turn on. Make sure that the main switch on the power supply unit is turned on. - Page 33 Chapter Troubleshooting Network Symptom Remedy The Disklavier cannot connect to the Internet via a Make sure that the wireless router (access point) is wireless router (access point). turned on. The Disklavier and the wireless router (access point) might be too far apart. Place the Disklavier and the wireless router (access point) closer to each other.
-
Page 34: Error Indications
Firmware update is failed. Turn the power off. Download the update program and try to update the firmware again. If the problem still persists, consult your Yamaha piano dealer. Two or more USB flash memories You can use only one USB flash are connected at the same time. -
Page 35: Chapter 5 Glossary
16 parts, and 128 standard voices. PianoSoft™ PianoSoft software contains prerecorded songs Incremental Pedal made by Yamaha specifically for use with the Piano pedals are not always completely up or down Disklavier. and may be held somewhere in-between. Using incremental pedal data (also called continuous or PianoSoftPlus™... - Page 36 Chapter Glossary Abbreviation for Standard MIDI File. Yamaha XG is an extension of the GM (General MIDI) format. Its greater polyphony, more voices, SMF Song Format and use of effects enhances the compatibility between MIDI devices. When a song in the...
-
Page 37: Chapter 6 Specifications
Specifications Chapter General Specifications Type Piano Grand Piano Upright Piano Grand Piano Non-contact optical fiber grayscale shutter sensing system for 88 keys (sensors for the key Key Sensors position, keying velocity, and key releasing velocity) Hammer Non-contact optical fiber/ Non-contact optical fiber/shutter sensing system Sensors grayscale sensing system Sensor... - Page 38 Chapter Specifications Type Piano Grand Piano Upright Piano Grand Piano Piano Sound CFX Binaural Sampling, CFX Stereo Sampling Pitch Control 414.8 Hz to 466.8 Hz (tunable in 0.2 Hz increments) Polyphony 256 notes (max.) 16 voices (Piano, Electric Piano 1, Electric Piano 2, Electric Piano 3, Harpsichord 1, Voices for Tone Harpsichord 2, Vibraphone, Celesta, Pipe Organ 1, Pipe Organ 2, Pipe Organ 3, Pipe Organ 4,...
- Page 39 ST/PRO Appendix...
-
Page 40: Xg Voice List
XG Voice List Voice Group Voice Name Element Voice Group Voice Name Element Piano GrandPiano Organ Perc.Organ2 GrndPianoKSP RockOrgan MellowGrPno RotaryOrgan PianoStrings SlowRotary Dream FastRotary BrightPiano ChurchOrgan BritePnoKSP ChurchOrgan3 ElecGrandPno ChurchOrgan2 ElecGrPnoKSP NotreDame DetunedCP80 OrganFlute LayeredCP1 Trem.OrganFl LayeredCP2 ReedOrgan Honkytonk PuffOrgan HonkytonkKSP Accordion... - Page 41 XG Voice List Voice Group Voice Name Element Voice Group Voice Name Element Bass TechnoBass Brass SynthBrass3 Orbiter JumpBrass SquareBass AnaVelBrass1 RubberBass AnalogBrass1 Hammer SynthBrass2 SynthBass2 SoftBrass MellowSyBass SynthBrass4 SequenceBass ChoirBrass ClickSynBass AnaVelBrass2 SynBass2Dark AnalogBrass2 SmoothSyBass Reed SopranoSax ModulrSyBass AltoSax DXBass SaxSection XWireBass...
- Page 42 XG Voice List Voice Group Voice Name Element Voice Group Voice Name Element Synth. Pad Itopia Ethnic Taisho-kin CCPad Kanoon BowedPad Kalimba Glacier Bagpipe GlassPad Fiddle MetallicPad Shanai TinePad Shanai2 PanPad Pungi HaloPad Hichiriki SweepPad Percussive TinkleBell Shwimmer Bonang Converge Altair PolarPad GamelanGongs...
-
Page 43: Xg Drum Kit List
XG Drum Kit List : Same as Standard Kit 1 : No Sound Bank Select MSB (0-127) Bank Select LSB (0-127) Program Change (0-127) Program Change (1-128) MIDI Alternate Key Off Standard Kit1 Standard Kit2 Room Kit Rock Kit Electro Kit Analog Kit Note # Note... - Page 44 XG Drum Kit List : Same as Standard Kit 1 : No Sound Bank Select MSB (0-127) Bank Select LSB (0-127) Program Change (0-127) Program Change (1-128) MIDI Alternate Key Off Dance Kit Jazz Kit Brush Kit Symphony Kit SFX Kit1 SFX Kit2 Note # Note...
-
Page 45: Midi Data Format
MIDI Data Format MIDI Channel Message (1) [ MIDI (Silent) ] Status byte 1st Data byte 2nd Data byte MIDI Reception MIDI Transmission Piano MIDI Events Song Panel Song MIDI Status Data (HEX) Parameter Data (HEX) Parameter Playback Part Operation Playback Input Channel... - Page 46 MIDI Data Format MIDI Channel Message (2) ■ Parameters Controlled by NRPN (Non-Registered Parameter Numbers) [ MIDI (Silent) ] NRPN Data Entry MIDI Reception MIDI Transmission Piano Parameter Data Range Song Panel Song MIDI Playback Part Operation Playback Input Channel —...
- Page 47 MIDI Data Format MIDI Parameter Change Table ■ MIDI Parameter Change Table (XG SYSTEM) [ MIDI (Silent) ] MIDI Reception MIDI Transmission Address Size Data XG Default Piano Parameter Description Song Panel Song MIDI Playback Part Operation Playback Input Channel 00-0F MASTER TUNE -102.4…0…+102.3 [cent]...
- Page 48 MIDI Data Format [ MIDI (Silent) ] MIDI Reception MIDI Transmission Address Size Data XG Default Piano Parameter Description Song Panel Song MIDI Playback Part Operation Playback Input Channel × × × × 00-7F CHORUS TYPE MSB Refer to Effect Parameter List 41(=CHORUS1) 00-7F CHORUS TYPE LSB...
- Page 49 MIDI Data Format ■ MIDI Parameter Change Table (MULTI EQ) [ MIDI (Silent) ] MIDI Reception MIDI Transmission Address Size Data Piano Parameter Description Song Panel Song MIDI Playback Part Operation Playback Input Channel 00-04 EQ TYPE flat, jazz, pops, rock, classic ×...
- Page 50 MIDI Data Format ■ MIDI Parameter Change Table (MULTI PART) [ MIDI (Silent) ] MIDI Reception MIDI Transmission Address Size Data XG Default Piano Parameter Description Song Panel Song MIDI Playback Part Operation Playback Input Channel 00-20 NOT USED × ×...
- Page 51 MIDI Data Format [ MIDI (Silent) ] MIDI Reception MIDI Transmission Address Size Data XG Default Piano Parameter Description Song Panel Song MIDI Playback Part Operation Playback Input Channel 28-58 PAT PITCH CONTROL -24…0…+24 [semitones] × × × × 00-7F PAT LOW PASS FILTER CONTROL -9600…0…+9450 [cent] ×...
- Page 52 MIDI Data Format ■ MIDI Parameter Change Table (DRUM SETUP) [ MIDI (Silent) ] MIDI Reception MIDI Transmission Address Size Data XG Default Piano Parameter Description Song Panel Song MIDI Playback Part Operation Playback Input Channel 00-7F PITCH COARSE -64…0…+63 ×...
- Page 53 … × × 11110000 = Exclusive status Refer to Parameter Change Table 01000011 = YAMAHA ID 0001nnnn = Device Number n=always 0 (when transmit), n=0-F (when recieve) 01001100 = Model ID 0hhhhhhh = Address High 0mmmmmmm mm = Address Mid...
- Page 54 Panel Operation Song Playback Channel String Resonance Depth × × × 11110000 = Exclusive status 01000011 = YAMAHA ID 01110011 = Clavinova ID 00000001 = Model ID (Clavinova common ID) 01010000 = SubID 00010001 = SubID 0000nnnn = Channel (00-0F)
-
Page 55: Midi Implementation Chart
MIDI IMPLEMENTATION CHART Yamaha Disklavier Date: 01-APR-2016 Model: ENSPIRE ST/PRO Version: 1.00 Function... Transmitted Recognized Remarks Default 1-16 1-16 Memorized Basic Channel Changed 1-16 1-16 Default Mode Messages × 3, 4 (m=1) *1, *2 Altered ***************** × 21-108 0-127 Note Number... - Page 56 P. O. Box 1, Hamamatsu, 430-8650 Japan Jan-16 Printed in Japan Copyright © 2016 Yamaha Corporation YH773A0...
