Epson TM-P60 Installation And Setup Manual

Epson TM-P60 Installation And Setup Manual

Hide thumbs Also See for TM-P60:

Advertisement

Quick Links

See also: Programming Manual , User Manual
E
TM-P60 W
P
PSON
IRELESS
RINTER
Installation and Setup Guide

Advertisement

loading

Related Manuals for Epson TM-P60

Summary of Contents for Epson TM-P60

  • Page 1 TM-P60 W PSON IRELESS RINTER Installation and Setup Guide...
  • Page 2 Epson TM P60 Wireless Printer Guide Record of Revisions Reference: Rev. Squirrel Date Comments Build Page, Paragraph July Initial Release 12/12 Appendix A: Changing the Auto Power Off Time 7/13 Epson TM-P60 Setup Guide | October 7, 2013 | pg-i...

  • Page 3: Table Of Contents

    Installing the Epson TM-P60 Windows Printer Driver ................5 Speeding up Printing........................9 Squirrel Printer Setup ........................... 11 Appendix A - Changing the Auto Power Off Time ................13 Required Files ........................... 13 Epson TM-P60 Setup Guide | October 7, 2013 | pg-ii...

  • Page 4: Overview

    VERVIEW The Epson TM-P60 is a wireless Windows printer that can be used with Squirrel Mobility or Squirrel mPOS. The printer should be configured to use the customer’s existing wireless network, and will connect to the Squirrel POS system using the Windows Printer Driver Support in Squirrel Printer Setup.
  • Page 5 4. Unzip the NetConfig.zip file and run NetConfig088d.exe 5. Once the NetConfig088d.exe is loaded you will see the Epson Configuration Tool screen. Select Tools and then Options. 6. From the Options list, select the COM and click OK. Epson TM-P60 Setup Guide | October 7, 2013| pg 2...
  • Page 6 8. Double click on the printer in the list to display the Network Card Property screen. 9. Select the TCP/IP tab and enter the IP address for the printer. Ensure that the “Get IP address” is set to Manual. Epson TM-P60 Setup Guide | October 7, 2013| pg 3...
  • Page 7 13. Once you see the new printer IP address appear you can disconnect the printer and reboot the printer. Once the Printer comes back online it will beep and the green power light will blink until the printer connects to the wireless network. Epson TM-P60 Setup Guide | October 7, 2013| pg 4...

  • Page 8: Installing The Epson Tm-P60 Windows Printer Driver

    1. Select the Advanced Printer Driver (downloads as the APD_454EWM.zip) and unzip it. 2. Run the APD_454EWM.exe 3. The Welcome screen appears, click Next> 4. Read and accept the terms of the License Agreement and click Next> Epson TM-P60 Setup Guide | October 7, 2013| pg 5...
  • Page 9 6. Click the Add button to add a new printer. 7. In the Select driver dropdown box, select the EPSON TM-P60 Receipt printer. You can give it a different Printer Name. In the Port Type dropdown box, select ‘Create an Ethernet Port’.
  • Page 10 8. Enter the IP address that you entered during the printer configuration. Click Next>. The printer is now listed in the Printer Configuration screen. Click Next>. 10. In the Select Features screen, click Next> Epson TM-P60 Setup Guide | October 7, 2013| pg 7...
  • Page 11 11. In the Start Copying Files screen, click Next>. • The driver will now finish the installation. 12. When complete, click Finish Epson TM-P60 Setup Guide | October 7, 2013| pg 8...

  • Page 12: Speeding Up Printing

    PEED UP RINTING 1. Select the Windows Start button, and choose Devices and Printers. 2. Right click on the Epson TM-P60 Receipt printer and select the Printer Properties Epson TM-P60 Setup Guide | October 7, 2013| pg 9...
  • Page 13 3. Select the Advanced tab and select the “Print directly to the printer” option. 4. Click Apply and then OK. 5. Right click the Epson printer again and select Printer Properties. Click the Print Test Page button. • Once the printer successfully prints the test page, you are finished setting up the printers in Windows and you can assign them in Squirrel Printer Setup.

  • Page 14: Squirrel Printer Setup

    QUIRREL RINTER ETUP Now that the Epson TM-P60 printer and its driver are configured, you can assign it to a Squirrel printer in order to print checks wirelessly. 1. Open the Squirrel Browser and select Advanced Setup. 2. Select Printer Setup.
  • Page 15 4. Choose the Epson TM-P60 printer from the dialog box 5. Exit and Save Printer Setup. Your Epson TM-P60 Printer is now set up as a Squirrel POS Printer and can be used to print checks wirelessly. Epson TM-P60 Setup Guide | October 7, 2013| pg 12...

  • Page 16: Appendixa - Changing The Auto Power Off Time

    A - C PPENDIX HANGING THE OWER The Epson TM-P60 is configured, by default, to power off automatically after 20 minutes of inactivity. You can increase this time to a maximum of 60 minutes. Required Files • MSWUTL_V24900E.msi (contained in the zip file attached to this document) O INCREASE THIS AUTO POWER OFF TIME 1.
  • Page 17 9. Click OK once. You should get the following message “Communication Condition coincides with the connected printer”, click OK. 10. Click Printer status 11. Select the Customize value tab 12. Click Get status Epson TM-P60 Setup Guide | October 7, 2013| pg 14...
  • Page 18 60 minutes. 15. Click Set status and then Save status. 16. Reboot the printer & perform another self-test. 17. Confirm the Auto Power off time now says the revised time. Epson TM-P60 Setup Guide | October 7, 2013| pg 15...
