AquaLink RS PureLink
®
• The PureLink system is an all-in-one saltwater chlorinator control system power center for use with AquaLink
RS PDA, All Button, Pool Link, or OneTouch
• The AquaLink RS PureLink power center converts AC power into low voltage DC current which is required by
the cell to perform the electrolysis.
• The LCD display offers monitoring of chlorine production, cell modes, salinity level, temperature, water fl ow
and diagnostics.
• The chlorine generator electronics are connected with the pool circulation pump electrical source so that the
electrolytic cell only operates when the pool pump is on. The fl ow portion of the fl ow/temp/salinity sensor is a
backup device only.
Nature 2 Fusion Sanitizing Vessel
• The sanitizing vessel uses a combination of an electrolytic cell and a mineral cartridge. The electrolytic cell
contains bipolar electrodes which perform the electrolysis and produce chlorine when energized with DC
current. Chlorine is generated as pool water containing salt passes through the cell. The chlorine production
can be varied by either adjusting the Chlorine Production Level on the power center or by varying the number
of hours the Nature
electrodes once every three (3) hours by reversing polarity. This does not interrupt the production of
chlorine.
The mineral cartridge delivers controlled trace amount of silve and copper that works in conjunction
with the chlorine to maintain an algae-free pool.
Flow/Temperature/Salinity/Sensor
• The fl ow portion of the fl ow/temp/salinity sensor helps detect if there is adequate water fl ow through the vessel.
• The salinity portion of the fl ow/temp/salinity sensor detects the level of salt in the pool water. This salt level is
displayed in grams per liter (GPL)* on the liquid crystal display (LCD) whenever the salinity button is pressed.
This eliminates the need for manual pool water salinity testing.
• Pool temperature is displayed by pressing the temperature button.
*1 gram per liter (GPL) = 1000 ppm (parts per million)
2.3 Product Specifi cations
Capacity
Replacement Nature 2 cartridge
(sold separately)
Important: The proper replacement
cartridge model is indicated on the
label of the vessel
Maximum operating pressure
Minimum flow rate
Maximum flow rate
Salt Level Requirement *
Recommeded Salt Level *
Vessel Dimensions
Power Pack Dimensions
Vessel Weight
Power Pack Weight
* Do not exceed 3,500 ppm
Nature Fusion Soft Installation and Operation Manual
2®
Power Center (For centralized pool control system, sold separately)
TM
Fusion Soft is on each day.
2
Nature 2 Fusion Soft 700
Up to 12,000 gal.
(45,000 L)
DuoClear ® 25 or Nature
#W28000 (single)
#W26000 (4-pack)
50 psi
30 gpm (114 lpm)
120 gpm (455 lpm)
3,000 - 3,500 ppm
3,000 ppm
10.6 lbs (4.8 kg)
25 lbs (11.3 kg)
controllers.
TM
The Nature Fusion Soft automatically cleans the
2
2 Fusion 25
16.5" L x 16" H x 14.5" D (42 cm x 40 cm x 37 cm)
14.5" L x 10" H x 6.5" D (37 cm x 25 cm x 17 cm)
Nature 2 Fusion Soft 1400
Up to 40,000 gal.
(151,000 L)
DuoClear 45 or Nature2 Fusion 45
#W28002 (single)
#W26002 (4-pack)
50 psi
30 gpm (114 lpm)
120 gpm (455 lpm)
3,000 - 3,500 ppm
3,000 ppm
11 lbs (5 kg)
25 lbs (11.3 kg)
