- Page 1 AQUAPURE® Ei WORKBOOK...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS The information contained in this technical guide is intended for Zodiac trained service personnel only. Electrical installation and repairs should only be performed by a certified electrician or Zodiac trained professional. and must comply with all national electric codes (NEC, Canadian, etc.). state and local law, ordinances, codes and regulations.
- Page 4 Zodiac® Pool Systems, Inc. Zodiac Academy 1-800-822-7933 zodiac.academy@zodiac.com Regional Extension_________________ www.trainyu.com/zodiac www.ZodiacPoolSystems.com Instructor: __________________________________________________ ext. _______ Sales person: ________________________________________________ ext. _______ Service Manager: ____________________________________________ ext. _______ Notes:...
-
Page 5: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS.....................6 COMPONENTS....................7 LOCATIONS ....................8 PLUMBING ...................... 9, 10 ELECTRICAL ....................11 - 13 OPERATION ....................14 MAINTENANCE ....................15 CELL CLEANING .................... 16 TROUBLESHOOTING ..................17 - 19 PARTS AND EXPLODED VIEW ..............20, 21... -
Page 6: Specifications
Models: • Hard Wired Unit part number – APURE35 • Plug-In Unit part number – APURE35PLG DISCONTINUED Hard Wired Unit - Dual Voltage 240/120 VAC Plug-In Unit – 120 VAC Only Up to 35,000 gallons Specifications: Maximum Operating Pressure: 50 psi Minimum Flow Rate: 40 gpm Maximum Flow Rate: 92 gpm Required Salt Level: 3.5 to 4.0 gpl (3500 to 4000 ppm) -
Page 7: Components
Components Components - Hard Wired Unit Power Cell Flow Salt Pack Flow Salt On/Off Output On/Off Output Upper Clamp 1½ inch Adapter Lower Clamp Components - Plug In Unit DISCONTINUED Power Cell Flow Salt Pack Flow Salt On/Off Output On/Off Output Upper Clamp... -
Page 8: Locations
Location Location - Hard Wired Unit Flow Salt Flow Salt On/Off utput On /Off Ou tp u Maximum 15 feet Cell should be the last piece of equipment Water Flow Water Flow Minimum 15 inches Location - Plug In Unit Flow Salt Flow... -
Page 9: Plumbing
Installation Installation - Clamping to Pipe Only needed if pipe is 1½ inch And here Tabs Step 1: Dissasemle clamping system by Step 2: Turn base over and place on top of pipe. Insert pressing on tabs. marker through each hole in the base and mark the pipe. Drill holes with the hole saw provided. - Page 10 Installation Installation - Cell Wiring Step 1: Remove cell terminal cover. • Follow color coding. • Run cable up channel. • Replace cover when complete. Step 2: Feed cable up the side of the cell and attach the color coded wires to the terminals. Replace cell cover.
-
Page 11: Electrical
Installation Installation - Wiring Hard Wired Unit Flow Salt Flow Salt On/Off utput On /Off Outp u Connect Power Pack to load side of switch, time clock or relay. Ground unit and bond all equipment. Installation - Wiring Plug In Unit Flow Salt Flow... - Page 12 Installation Installation - Opening Power Pak Fl Fl o o w w S S al a t lt Flow Salt On On / / Of Of f f Ou Ou t t p p u u t t On/Off Output 2.5 amp fus es 100-265 VAC 2.5 amp fus es...
- Page 13 Installation Salt • Ocean water – 35,000 to 36,000 ppm. • Tear drop – 7,200 ppm. • Ei – 3,500 to 4,000 ppm. The purer the salt the better. Calcium & Magnesium are enemies of the cell. Pure NaCl • Minimum 98% pure food grade NaCl •...
-
Page 14: Operation
Operation Operation When power is first applied to the Ei, it will display the software revision, then default to Off. Polarity Reversal • The Ei reverses polarity every 5 hours of operating time. • When reversing polarity, “CLEANING” is displayed. •... -
Page 15: Maintenance
Operation Change Polarity Reversal Time The Ei is set to reverse polarity every 5 hours. This can be changed to every 2.5 hours. Press the ON/OFF button and the hidden button (under the Jandy label) simultaneously. Notes:... -
Page 16: Cell Cleaning
Troubleshooting - No Flow No Flow LED • “NO FLOW” is displayed when there is insufficient or no water flow through the cell. • The minimum flow rate is 40 gpm. • It may also activate if the flow pod is installed at more than 45° to the verticle or if the flow switch paddle has been turned within the flow pod. - Page 17 Troubleshooting - Salt Check Salt The ideal salt level is 4000 ppm and the ideal water temperature is 80º F. The CHECK SALT light will illuminate & the LCD will read “Check Salt” • If the water temp is below 65º F •...
-
Page 18: Troubleshooting
Troubleshooting Help Hard Reset The Ei has a ‘hidden HARD RESET button located to the right of the Jandy logo, that can be used to reset the microcontroller. This button is located as shown in the picture. Press to RESET. OutPut Fault OUTPUT FAULT is displayed when there is a problem with the power supply (service required) - Page 19 Troubleshooting Comm Test Communication With Controls To change: The default is set to Jandy L/M. • This setting will communicate with Turn the Ei OFF, then press and hold the OUTPUT button for ~6 all AquaLink current systems. seconds. • Continue holding the OUTPUT button until the desired controller setting is displayed on the screen.
-
Page 20: Parts And Exploded View
Maintenance Maintenance For Section references see the AquaPure Ei I/O Manual #: H0331400 Notes:... - Page 21 Maintenance Notes:...
- Page 22 Quick Guide AquaPure Ei Troubleshooting – Sections references are for the installation manual ®...
- Page 23 Quick Guide AquaPure Ei Troubleshooting – Sections references are for the installation manual ®...
- Page 24 Quick Guide AquaPure Ei Troubleshooting – Sections references are for the installation manual ® Notes:...
- Page 25 Replacement Parts and Exploded Views...
- Page 26 Notes:...
- Page 27 Notes:...
- Page 28 DVS Ei May 2015...
