CLP-150/CLP-150M/

PARTS LIST

CONTENTS
OVERALL ASSEMBLY ........................... 2
MAIN UNIT ............................................. 4
TOP BOARD ASSEMBLY ...................... 9
PANEL ASSEMBLY .............................. 10
MUSIC REST ASSEMBLY ................... 13
ARM ASSEMBLY ................................. 14
FRONT RAIL ASSEMBLY .................... 15
END BLOCK ASSEMBLY .................... 16
KEY COVER ASSEMBLY .................... 17
JACK ASSEMBLY ................................ 18
HEADPHONES JACK ASSEMBLY ...... 19
Notes : DESTINATION ABBREVIATIONS
A : Australian model
B : British model
C : Canadian model
D : German model
E : European model
F : French model
H : North European model
I : Indonesian model
J : Japanese model
K : Korean model
WARNING
Components having special characteristics are marked Z and must be replaced with parts having speci-
fication equal to those originally installed.
The numbers "QTY" show quantities for each unit.
The parts with "--" in "PART NO." are not available as spare parts.
This mark " } " in the REMARKS column means these parts are interchangeable.
The second letter of the shaded (
The second letter of the shaded (
CLP-150C
) part number is O, not zero.
) part number is I, not one.
DM ASSEMBLY .................................... 19
MA120 ASSEMBLY .............................. 20
FU120LB ASSEMBLY .......................... 21
SIDE BOARD UNIT .............................. 22
PEDAL BOX ASSEMBLY ..................... 24
PEDAL ASSEMBLY .............................. 25
KEYBOARD ASSEMBLY ..................... 26
BENCH(BC-102DR/BC-102MH/BC-102CH) ..... 28
BENCH(BC-100DR/BC-100MH/BC-100CH) ..... 29
ELECTRICAL PARTS .................. 30 – 45
M : South African model
O : Chinese model
Q : South-east Asia model
T : Taiwan model
U : U.S.A. model
V : General export model (110V)
W: General export model (220)
N,X : General export model
Y : Export model
