Function of the serial number
(1) Pitch and Modulation wheels

(2) Volume clipper potentiometer

(3) Unlimited rotation data regulator

(4) Drum PAD

(5) Octave buttons- (DOWN)
(6) Octave buttons+ (UP)
(7) Metronome (TAP)
(8) Arpeggiator (ARP)
(9) CHORD
(10) SET
(11) Switch A/B (Drum PAD)
(12) Tick device(BEAT)
(13) Transpose+/-
(14) Velocity Curve(NORM/HEAVY/SOFT)
(15) Arpeggiator mode(ARP MODE)
(16) Arpeggiator/Tick time(ARP TIME/BEAT TIME)
(17) Keyboard Scale(SCALE)
(18) PAD Operating mode(PAD MODE)
(19) Reset the parameters(Reset)
(20) Pedal switch(SUSTAIN)
(21) USB 2.0
(4) Functions overview：

4.1 Pitch and Modulation wheel:

Pitch wheel: Transmits MIDI Pitch Bend information to raise or lower the pitch of a
note temporarily.
Modulation wheel: This wheel can be used to transmit continuous controller data
(CC #1 or Modulation Depth).
4.2 Volume clipper potentiometer
The potentiometer can adjust the MIDI volume, adjust the volume potentiometer
will transmit the MIDI messages.

4.3 Unlimited rotation data regulator (Data):

Unlimited rotation data regulator to send specific controller information, you can
use MIDI Editor software editing a CC value.
4.4 Drum PAD:
Drum PAD: Send PAD MIDI information, you can use MIDI Editor software editing
a CC value
4.5&4.6 Octave buttons (DOWN& UP):
Octave buttons(DOWN& UP)，can be used to enlarge the 0-key to 88-key or
more。Every time to reduce or increase an octave(the default value of 4)，
1. To reduce an octave (octave value less than 4)"OCTAVE UP" LED light;
2. To increase an octave (octave is greater than 4)"OCTAVE DOWN"LED light;
