Description

2 Description
2.1

Introduction

The Anybus X-gateway consists of two Anybus fieldbus or Ethernet network interface modules
and an intelligent gateway platform which transfers data between the two networks.
The X-gateway can be configured via a USB port using a Windows-based application, Anybus
Configuration Manager. The on-board network interfaces are normally configured from the re-
spective networks, using third-party configuration tools.
Network 1
Network 2
Fig. 1 Anybus X-gateway concept overview
This document describes only the gateway platform. The network interfaces are described in
the respective Network Guides that can be downloaded from www.anybus.com/support.
®
