Section 2: General Information

The Generator

A
P
O
A. Lock with Cover
B. Main Line Circuit
Breaker (Generator
Disconnect)
C. Airbox with Air Cleaner
D. Control Panel
Owner's Manual for 50 Hz Air-Cooled Generators
L
Q
N
M
Figure 2-1. Components and Control Locations
E. Battery Compartment
(Battery not supplied)
F. Exhaust Enclosure
G. Status LED Indicators
H. Oil Drain
B
F
C
D
E
J
K
H
J. Oil Fill Cap
K. Oil Filter
L. Composite Base
M. Oil Dipstick
General Information
G
A
001786
N. Sediment Trap
O. Fuel Regulator
P. Fuel Inlet
Q. Data Plate Location
