Audiovox DS9106 Instruction Manual

Audiovox 9" portable dvd player owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C HA RGE
POW ER
DS9106/DS9106PK
9" Portable DVD Player

Advertisement

Table of Contents
loading

Related Manuals for Audiovox DS9106

Summary of Contents for Audiovox DS9106

  • Page 1 C HA RGE POW ER DS9106/DS9106PK 9" Portable DVD Player...

  • Page 2: Table Of Contents

    Table of Contents A. Introduction ... 7 B. DVD and Disc Information ... 7 C. Contents ... 8 D. Powering and Installation ... 8 E. Vehicle Installation ... 9 F. Controls, Indicators, and Connectors...10 G. Loading and Playing a Disc ... 12 H.
  • Page 3 Important Safety Instructions Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use. Read all instructions prior to use. Keep these instructions. Heed all warnings. Follow all instructions.
  • Page 4 Additional Safety Information An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the parking brake is not applied must be installed to the rear of the driver’s seat where it will not be visible, directly or indirectly, to the operator of the motor vehicle.
  • Page 5 FCC Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 6 Manufacturer Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 Service Information This product should be serviced only by those specially trained in appro- priate servicing techniques. For instructions on how to obtain service, refer to the warranty included in this user manual.

  • Page 7: Introduction

    A. Introduction Thank you for choosing the DS9106/DS9106PK portable DVD player. The main features include a 9" wide Screen (16:9 Aspect Ratio) Liq- uid Crystal Display (LCD) monitor and a DVD player. The unit ap- plies the latest state of the art electronics and is designed for use in hotels, offices or your home.

  • Page 8: Contents

    6. 1 x Instruction Manual 7. 1 x Product Registration Card 8. 1 x eMusic Card * DS9106 & DS9106PK can operate on a fully charged battery for six hours. ** Only for DS9106PK. D. Powering and Installation 1. Powering the System Indoors (Refer to Figure 1)

  • Page 9: Vehicle Installation

    E. Vehicle Installation Installing the DVD Player onto the Seat Back in a Car (Refer to Figure 2) Carrying Bag Opened Carrying Bag Closed Elastic Straps Vehicle Headrest Vehicle Seat Back 1) Unfold the carrying bag, and place the DVD player on the bag beneath the elastic straps.

  • Page 10: Controls, Indicators, And Connectors

    F. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 3) Swivel CHARGE POWER Figure 3...
  • Page 11 Power Button 2) Setup Button 3) Source Button 4) Display Button 5) Repeat Button Previous Button Next Button 8) Menu Button 9) Stop Button 10) UP/AUDIO button Left/Fast Backward Button Right/Fast Forward Button * Connecting to the headphone jack will disable the internal speakers. 2.Remote Control View (Refer to Figure 4) 1) Setup Button 2) Up Button...

  • Page 12: Loading And Playing A Disc

    G. Loading and Playing a Disc a. After connecting power to the unit, press the ON the unit. The power indicator will turn green. b. Open the disc tray by pressing the OPEN button and place a disc Into the tray with the label side facing up. c.

  • Page 13: Menu

    I. Menu A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 14 c. Press the DISPLAY button a third time to display the Elapsed Time for the chapter. TT 01 01 CH 02 17 Chapter Elapsed Time Screen Display d. Press the DISPLAY button a fourth time to display the Remaining Time for the chapter. TT 01 01 CH 02 17 Chapter Remaining Time Screen Display e.
  • Page 15 2. Subtitle During disc playback press the SUBTITLE button to select the sub- title language you desire*, with the current Subtitle Language Num- ber (1) and the total Number of Subtitle Languages (2) displayed. If there are multiple languages, press the SUBTITLE button again to select another subtitle language.
  • Page 16 4. Zoom During playback press the ZOOM button to enlarge the picture by 2x, 3x or 4X. Press the ZOOM button once, the picture will be enlarged 2X. Press the ZOOM button twice, the picture will be enlarged 3X. Press the ZOOM button a third time, the picture will be enlarged 4X. Press the ZOOM button a fourth time, the picture will return to normal size.
  • Page 17 b. Press the REPEAT button again to repeatedly play the current title. Title Repeat ON Screen Display c. Press the REPEAT button a third time to repeat all chapters and titles. All Repeat ON Screen Display d. Press the REPEAT button a fourth time to resume normal playback. Repeat Off Screen Display...

  • Page 18: Playing Audio Cds

    K. Playing Audio CDs To play an audio CD, load it onto the disc tray and the CD will start playback automatically. Press the DISPLAY button repeatedly on the remote control or the unit to view disc information. The time information is displayed in the the following sequence: Single Elapsed Display Off...

  • Page 19: Playing Jpeg Files

    L. Playing JPEG Files 1) Load a JPEG disc into the disc tray. 2) A screen showing folders or picture files contained on the disc will be displayed automatically after loading. 3) Press and OK buttons to select a folder or a picture. If a picture is selected, a photo slideshow will start with the selected picture.

  • Page 20: Connecting To Other Electronic Equipment

    M. Connecting to Other Electronic Equipment 1. Connecting to a TV or Another Monitor ( Refer to Figure 4) a. Connect one end (1/8" stereo plug) of the audio cable (not supplied) into the unit’s AUDIO OUT jack. Connect the other end (2 RCA jacks) to the Left and Right channel audio input jacks on your TV or monitor.

  • Page 21: Setup

    N. Setup Press SETUP button to display the Main screen of the SETUP Menu on the screen. Press SETUP button again to exit the SETUP Menu. 1. General Setup Page Press SETUP, the ‘GENERAL SETUP PAGE’ will display on the screen.
  • Page 22 b) Angle Mark Select ‘ANGLE MARK’ using the DOWN buttton, and then press the RIGHT button to enter the submenu. Choose Angle Mark on or off using the UP/DOWN button and then press the OK button to confirm the set ting.
  • Page 23 e) Screen Saver Select ‘SCREEN SAVER’ using the DOWN button and then press the RIGHT button to enter the submenu. Choose Screen saver on or off using the UP/DOWN buttons and then press the OK button to confirm the setting. Press the LEFT button to return. TV D isplay Angle M ark O SD Lang...
  • Page 24 2. Video Quality Setup Select ‘VIDEO QUALITY SETUP’ page by using the LEFT/RIGHT button, press the OK button to enter the ‘VIDEO QUALITY SETUP’ page. Br ight ness C ont rast H ue Satur ation G o To Video Setup P age Video Setup Page Screen Display a) Select ‘BRIGHTNESS’...
  • Page 25 3. Password Setup Select ‘PASSWORD SETUP PAGE’( buttons, then press the OK button to enter the submenu. Passwor d Setup Page Passwor d C hange Passwor d Password Setup Page Screen Display Press the OK button twice to enter the PASSWORD CHANGE PAGE.
  • Page 26 4. Preference page With no disc inside the player select ‘PREFERENCE’( the LEFT or RIGHT button, then press the OK button to enter the ‘PREFERENCE PAGE’. Pr eference Page Audio Subtitle D isc M enu Par ental D ef ault G o To P reference P age Preference Page Screen Display a) Audio...
  • Page 27 b) Subtitle Select ‘SUBTITLE’ using the DOWN button, then press the OK button to enter the submenu. Select the desired subtitle language or OFF using the UP or DOWN buttons, then press the OK to confirm the setting. Press the LEFT to return. Pr eference Page Audio Subtitle...
  • Page 28 d) Parental Select ‘PARENTAL’ using the DOWN button, then press the OK button to enter the submenu. Pr eference Page Audio Subtitle D isc M enu Par ental D ef ault Set Parental Control Parental Preference Screen Display Select the parental level you desire using the UP or DOWN button for discs with lock-out function or multiple rating levels.

  • Page 29: Specifications

    O. Specifications Compatible DISC: DVD, CD Signal system: NTSC Panel size: 9 inch Frequency response: 20 Hz to 20 kHz Video output: 1 Vp-p/75 Ohm, unbalanced Audio output: 1.4Vrms/10kOhm Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm Power source: DC 9-12V Power consumption: 7W...
  • Page 30 Each full recharge takes approximately seven hours. During recharge, the red indicator will stay on. Once fully recharged, the red light will turn off. At this point you may remove the wall plug and stop charging. Precautions Related to Battery Recharge: 1.

  • Page 31: Troubleshooting

    Q. Troubleshooting PROBLEM • Make sure the DVD player is connected No sound or distorted sound properly. Make sure all cables are securely inserted into the appropriate jacks. • You can’t advance through the opening Can’t advance credits and warning information that appears through a movie at the beginning of movies because the disc is programmed to prohibit that action.
  • Page 32 Troubleshooting (Cont) PROBLEM • Check the type of disc you put into disc Disc won’t play tray. This DVD player only plays DVDs and audio CDs. • Your DVD player has been designed to process regional management information that is stored on DVD discs. The regional code for your player is 1 Play starts, but (The U.S.,U.S.

  • Page 33: Day Limited Warranty

    90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within ninety (90) days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.

This manual is also suitable for:

Ds9106pk
