Page 7
Installation instr. F13DGA Version: V1.0 Seite: Autor: Datum: 15.05.2014 AWRON GmbH Disassembly interior trim Remove with a plastic wedge the interior trim. Start from the right. Pay attention to the connectors. Remove interior trim Remove black connector...
Page 8
Installation instr. F13DGA Version: V1.0 Seite: Autor: Datum: 15.05.2014 AWRON GmbH Disassembly interior trim See picture Remove cable from fixing point...
Page 9
Installation instr. F13DGA Version: V1.0 Seite: Autor: Datum: 15.05.2014 AWRON GmbH Disassembly interior trim Remove white connector Remove the interior trim and prepare for dismantling...
Page 10
Installation instr. F13DGA Version: V1.0 Seite: 10 Autor: Datum: 15.05.2014 AWRON GmbH Dismantling air grill Use T15 Torx screwdriver Unscrew all screws, see arrows...
Installation instr. F13DGA Version: V1.0 Seite: 11 Autor: Datum: 15.05.2014 AWRON GmbH Dismantling interior trim Air grill take out Install F1xDGA display module...
Page 12
Installation instr. F13DGA Version: V1.0 Seite: 12 Autor: Datum: 15.05.2014 AWRON GmbH Disassembly panel under the glove box on driver side Unleash screws. Wrench size 10mm Fold down the the cover...
Page 13
Installation instr. F13DGA Version: V1.0 Seite: 13 Autor: Datum: 15.05.2014 AWRON GmbH Remove the OBD connector Unlock the blue locking clip in direction of arrow Pull out the OBD connector as well as the footwell lighting, see arrows...
Page 14
Installation instr. F13DGA Version: V1.0 Seite: 14 Autor: Datum: 15.05.2014 AWRON GmbH Uncovering of the connector on ZGM gateway controller ZGM gateway control unit in the footwell top left Unlock and disconnect the blue connector...
Page 15
Installation instr. F13DGA Version: V1.0 Seite: 15 Autor: Datum: 15.05.2014 AWRON GmbH Uncovering of the connector on ZGM gateway controller Unlock the Black plug Remove the black plug...
Page 16
Installation instr. F13DGA Version: V1.0 Seite: 16 Autor: Datum: 15.05.2014 AWRON GmbH Pull off black cover cap Pinene out cable Pin 41 (yellow), Pin 46 (blue / red) and pin 47 (red)
Page 17
Installation instr. F13DGA Version: V1.0 Seite: 17 Autor: Datum: 15.05.2014 AWRON GmbH Picture showing right connection on booth connector (white and blue).
Page 18
Installation instr. F13DGA Version: V1.0 Seite: 18 Autor: Datum: 15.05.2014 AWRON GmbH Uncovering of the connector on CAS control unit CAS in the footwell on the top right Remove the black plug...
Page 19
Installation instr. F13DGA Version: V1.0 Seite: 19 Autor: Datum: 15.05.2014 AWRON GmbH Uncovering of the connector on CAS control unit Pull the cap 12 14 Auspinen cable to pin 14 (green / white) and pin 12 brown / black)
Page 20
AWRON GmbH Cable to pin 12 (brown / black) and pin 14 green / white) from AWRON harness coming into the plug again pinene back. The out pints cable into the black connector pinen and insert it into the black...
Page 21
Installation instr. F13DGA Version: V1.0 Seite: 21 Autor: Datum: 15.05.2014 AWRON GmbH Assembly AWRON display Display connector out lead at the top of the shaft. Connect F1 XGA display module and assemble everything...
Page 22
Autor: Datum: 26.03.2014 AWRON GmbH Support & FAQs For all enquiries concerning your AWRON display system, or if you Please also seen us and our have problems with installation another AWRON products on guide the AWRON support team our website www.awron.de...
