Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 Table of contents Model support Product description System components Operating concept key functions Sprint function S.10 Software update S.11 Purchased parts package S.12 Technical data S.13... - Page 3 Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 Model support BMW 3 E-Serie E46- Coupé Compressor Kit All models with following engines are Turbo- Gasoline Gasoline engine Diesel- engine supported: engine...
-
Page 4: E46Dga
Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 Product description E46DGA Display system Data display: Boost pressure • Tourque • Performance • Sprint • Lateral and Longitudinal accelaration • Performace chart • Maximum values • Visually, the display fits perfectly into the Interior. -
Page 5: System Components
Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 System components Boost pressure display 1 Battery voltage 3 Peek holder bar Indicates the current battery voltage Graphically represents the boost pressure, between 0 and 1.35 bar, and is equipped with a towing pointer... - Page 6 Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 System components Sprint display Specifies currently speed in km/h according to the speedometer 3 max. Speed 1 Speed Specifies the time depending on the current speed Indicates the ever reached maximum speed in km/h...
- Page 7 Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 System components Exhaust and intake temperature screen 1 Exhasut temperature Specifies of the exhaust temperature in °C Specifies of the air intake temperature in °C Specifies of the air intake temperature in °C 2 Air intake Specifies of the boost temperature in °C...
- Page 8 Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 System components Oxygen values Specifies the current value of wideband oxygen sensor Bank 1; measures the residual oxygen content in the exhaust gas; λ > 1 = lean mixture; λ < 1 = oily mixture;...
- Page 9 Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 System components Maximum values Specifies the maximum value of the current drive; When the switch off the 1 Maximum values ignition deletes these values Switch off display During the brief wait about 2 seconds, the display turns off; by pressing the...
-
Page 10: Operating Concept
21.11.2015 Operating concept Key functions To operate the Display E46DGA you just have to use the sterring wheel buttons. Each a press of a specified button ( for example the hash key) is enough, to switch between the displays. This allows an easy handling and ensures the control of the vehicle by the driver. -
Page 11: Sprint Function
Article: Version: Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 Operating concept Sprint function The sprint display is operated only by the driving style of the driver. So they are not any external buttons for the operation necessary. In the stand is the stopwatch, as well as the speed to 0. -
Page 12: Softwareupdate
Software updates are available for the operating systems Windows XP and Windows 7. Required software is available for download at Awron.de. Then the computer has to be connected with the display system via USB and the required driver software installs itself automatically. -
Page 13: Purchased Parts Package
Date: Awron GmbH 21.11.2015 Purchased parts package Display system E46DGA Display system Only 2 parts are included: Cable harness incl. USB connection, display system. This purchased parts package ensures an assembly true the motto of „plug and play“. The wiring harness is connected directly to the can bus, which ensures a precise data transmission. -
Page 14: Technical Data
Page: E46DGA V1.0 Author: Date: Awron GmbH 21.11.2015 Technical data E46DGA Display system Display •OLED display 320 x 240 Cutting point •CAN – Bus 1 Mbit •USB cutting point for Software update Case • Plastic, original BMW air grille Size (length x width x depth) •...
