Page 2: Table Of Contents
Artikel: Version: Seite: F1x DGA V1.0 Autor: Datum: Awron GmbH 31.12.2013 Table of contents F1xDGA Table of contents Modell support Product description System components Operating concenpt S.13 key functions S.13 Sprint function S.15 Quarter mile function S.16 Software update S.18 Purchased parts package S.19... -
Page 3: Modell Support
Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Modell support F13DGA 6 F-Series F13- M6 All models with following engines are supported: Turbo- Gasoline engine... -
Page 4: Product Description
Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Product description F13DGA Product desription Messwertdatenanzeige: Boost pressure • Tourque • Performance • Leistungsdiagramm • Lateral and Longitudinal accelaration • Sprint • Quarter of a mile • Lambda values and exhaust gas temperature •... -
Page 5: System Components
Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 System components Boost pressure display 1 Battery voltage 3 Peek holder bar Indicates the current battery voltage Graphically represents the boost pressure, between 0 and 1.35 bar, and is equipped with a towing pointer... - Page 6 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 System components Performance display 1 Battery voltage 3 Peek holder bar Indicates the current battery voltage Represents the power between 0 and 400 PS and is equipped with a peek holder...
- Page 7 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Systemkomponenten Lateral and Longitudinal accerlaration 1 Longitudinal Specifies the longitudinal acceleration in G (G= 9,81 m/s acceleration Graphically represents the longitudinal acceleration, between 0,8G backwards and 0,8G forwards and is equipped with a drag indicator...
- Page 8 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Systemkomponenten Quarter mile - Display 1 Stopwatch Measures the time up to reach the quarter mile Shows the maximum values of the last ride; the values are overwritten at the...
- Page 9 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Systemkomponenten Wideband oxygen and exhaust Specifies the current value of wideband oxygen sensor Bank 1; measures the temperature 1 wideband residual oxygen content in the exhaust gas; λ > 1 = lean mixture; λ < 1 = oily oxygensensor Bank 1 mixture;...
- Page 10 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Systemkomponenten Intake temperature, oil temperature, fuell pressure (only for diesel engines) 1 Intake temperature Specifies the intake temperautre from 0 bis 130 °C Specifies the current oil temperature from 0 to 130 °C...
- Page 11 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Systemkomponenten Maximum values Page 2 (only for diesel engines) Specifies the maximum value of the current drive; When the switch off the 1 Maximum values ignition deletes these values Maximum values Page 3...
- Page 12 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Systemkomponenten Switch off display 1 Switch off display During the brief wait about 2 seconds, the display turns off; by pressing the wheel button it is possible to turn the display back...
-
Page 13: Operating Concenpt
Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Operating concenpt F13DGA Key functions The display F1xDGA is operated above the already existing rocker switch on the steering wheel of speed control. If the cruise control is switched off, you can switch back and forth between the individual system components. - Page 14 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Operating concenpt F13DGA Key function To change settings, move the rocker switch to bottom until one has arrived at the desired setting. Move the rocker switch above to confirm or to change the setting.(E.g.
-
Page 15: Sprint Function
Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Operating concenpt F13DGA Sprint function The sprint display is operated only by the driving style of the driver. So they are not any external buttons for the operation necessary. In the stand is the stopwatch, as well as the speed to 0. - Page 16 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Operating concenpt F13DGA Quarter mile display ¼ mile Reaction time Measurement speed measurement 660 Foot 660 Foot Preparation time 60 Foot Timer 660 Foot Timer ¼ mile timer The quarter mile display of F1xDGA serves the riders to perform a drag racing with exact measurements. Due to a short preparation time of 10 seconds, the driver can prepare for the race.
- Page 17 Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Operating concenpt F13DGA Quarter mile display Preparation phase Traffic lights - countdown Measurement the quarter mile screen can be The small yellow upper lights The stored path is symbolized operated not through additional...
-
Page 18: Software Update
Software updates are available for the operating systems Windows XP and Windows 7. Required software is available for download at Awron.de. Then the computer has to be connected with the display system via USB and the required driver software installs itself automatically. -
Page 19: Purchased Parts Package
Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Purchased parts package F13DGA Purchased parts package Purchased parts package •Display system Display system •Cable harness incl. USB connection •Operating instructions This purchased parts package ensures an assembly true the motto of „plug and play“. -
Page 20: Technical Data
Article: Version: Page: F13DGA V1.0 Author: Date: Awron GmbH 10.03.2014 Technical data F13DGA Technical data Display •OLED display 320 x 240 Cutting point • CAN – Bus 500 KBit • USB cutting point for Software update Case •Plastic, original BMW air grille Size (length x width x depth) •...
